Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCR
-
Groupset Alivio, Deore -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A6-SL Quaternary phase Aluminum, custom butted, integrated Tapered headset with 1 1/2" lower bearing, hydroformed top and down tube, water bottle mount
Suspension Fork
Suntour XCR 29" 100mm Travel, w/Mechanical Lock Out
Rear Shock
ROCKSHOX Bar 2.1
Drivetrain
Rear Derailleur
Shimano Alivio SGS Top Normal, 9sp
Front Derailleur
Shimano Alivio, 34.9mm
Shift Levers
Shimano Alivio, 27-speed
Cassette
Shimano Cassette, 11-34T 9sp
Crank
Shimano Deore M-542 22/32/44T
Bottom Bracket
Shimano Press In Bearing system
Chain
Shimano HG-73
Pedals
none
Wheels
Rims
Fuji Custom 32H MTB 6-Bolt Disc Hubs with WTB Speed Disc All MTN 29" Rims
Tires
WTB Prowler SL Race, 29x2.1" Kevlar Bead Folding
Brakes
Brakes
Tektro Novela Mechanical Disc Brake 180/160mm Rotor
Brake Levers
Tektro Linear Pull
Cockpit
Stem
Oval M-200 RBT 6061 Alloy Stem, 31.8mm
Handlebar
Oval M-200 Double Butted 6061 Flat Bar , 31.8mm
Headset
Fuji MTB 1 1/8-1 1/5" Semi-Integrated, 30mm spacers
Seat
Saddle
Oval M-200 w/CrMo Rails
Seatpost
Oval M-200 31.6x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 332 mm | 332 mm | 332 mm |
| Top Tube Length | 595 mm | 610 mm | 639 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 432 mm | 482 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Chainstay Length | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1132 mm | 1148 mm | 1177 mm |
| Bottom Bracket Drop | 42 mm | 42 mm | 42 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Outland 29’er 3.0 belongs to the Fuji Outland model. 69 bikes variations carry this model name so far. You can easily view all of the Fuji Outland bikes models from 2011, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Crosscountry bikes
On a deeper look, we notice that the average weight of a Crosscountry bike is 12.4 kg (27.34 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Outland 29’er 3.0 weighs 14.8 kg (32.63 lbs) and is much heavier than the average. To sum up, it’s 19.35% heavier than the average weight of Crosscountry bikes.
Outland 29’er 3.0 components
Fork
The fork installed on this bike is the SunTour XCR model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on Outland 29’er 3.0 are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Outland 29’er 3.0 has Mechanical Disc brakes installed. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
