Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Fox Performance Float 32
-
Groupset XT, Deore -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL custom-butted alloy tubing w/ hydroformed top tube, tapered 1 1/8" - 1.5" head tube, PF30 bottom bracket, sealed cartridge bearing pivots
Suspension Fork
Fox 32 FLOAT 29 Performance FIT 3-position w/ remote lockout, tapered alloy steerer, 15x110mm thru axle, 120mm travel
Rear Shock
Fox Float Performance 3-position
Drivetrain
Rear Derailleur
Shimano Deore XT shadow plus, 10-speed
Front Derailleur
Shimano Deore, side swing, direct-mount
Shift Levers
Shimano Deore Ispec, Rapid Fire, 20/30-speed
Cassette
Shimano HG-50, 11-36T, 10-speed
Crank
Shimano Deore, hollow Tech II w/ integrated spindle, 36/22T
Bottom Bracket
Shimano sealed cartridge, PF30 adaptor included
Chain
KMC X10 w/ Missing Link, 10-speed
Pedals
N/A
Wheels
Rims
Oval Concepts 600 CL disc wheelset, 28h, 15x110mm front, 148x12mm rear, cartridge bearing hubs, welded rims, stainless spokes
Tires
Schwalbe Rocket Ron Performance, 29" x 2.25" 67tpi, folding
Brakes
Brakes
Shimano M447, hydraulic disc, 180/160mm rotors
Brake Levers
Shimano M506, hydraulic disc
Cockpit
Stem
Oval Concepts 313, 6061 3D-forged alloy, 31.8mm clamp diameter, 7° rise
Handlebar
Oval Concepts 250, 6061 alloy, riser, 31.8mm, 9° sweep, +/- 5mm rise
Headset
FSA NO. 9M/12B, 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Oval Concepts 200 w/ steel rails
Seatpost
Oval Concepts 300, 6061 alloy, 30.9mm, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.45 mm | 1.41 mm | 1.32 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 663 mm | 698 mm | 721 mm | 750 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 89 mm | 89 mm | 89 mm | 89 mm |
| Stack | 608.3 mm | 608.3 mm | 617.6 mm | 617.6 mm |
| Reach | 383.8 mm | 418.8 mm | 438.2 mm | 467.2 mm |
| Top Tube Length | 553 mm | 588 mm | 610 mm | 639 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 381 mm | 431.8 mm | 482.6 mm | 533.4 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 105 mm | 105 mm | 115 mm | 115 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1108 mm | 1143 mm | 1166 mm | 1195 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm | 32 mm |
| Standover Height | 764 mm | 774 mm | 773 mm | 790 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Rakan 29 1.5 is part of the Fuji Rakan model. 37 bikes variations carry this model name so far. Take a sneak peek at all Fuji Rakan bikes models from 2016, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Trail bikes
If we make a quick analysis of the average weight of a Trail bike, we get 12.98 kg (28.62 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Rakan 29 1.5 weighs 13.47 kg (29.7 lbs) and is slightly heavier than the average. In conclusion, the average Trail bike weighs 3.78% less than Rakan 29 1.5.
Overview of components
Fork
The Fox Performance Float 32 is included from the factory. It has a travel distance of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
As for the wheels, Fuji Rakan 29 1.5 2016, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Rakan 29 1.5 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Rakan 29 1.5 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
