Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Recon Silver RL
-
Groupset Deore, FSA -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 170cm
MD
168cm - 176cm
LG
174cm - 185cm
XL
173cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL super-butted alloy front and rear triangle, Enduro Max sealed cartridge bearings, MLink patented suspension system, Boost 148x12mm, 120mm
Suspension Fork
RockShox Recon RL 29 Solo Air w/ tapered alloy steerer, Boost 110x15mm, 130mm travel
Rear Shock
RockShox Deluxe Select R
Drivetrain
Rear Derailleur
Shimano Deore, shadow plus
Shift Levers
Shimano Deore, Rapid Fire, 1 x 10-speed
Cassette
Shimano HG-500, 11-42T
Crank
FSA Gamma Pro, 30T
Bottom Bracket
FSA Mega EXO, threaded
Chain
KMC X10
Wheels
Rims
WTB ST i29 TCS 2.0 32H, Shimano MT400 front hub, MT400 rear hub, stainless black spokes
Tires
Maxxis Minion DHF, 29" x 2.30", 60tpi, EXO, Tubeless Ready, folding, Maxxis Aggressor, 29" x 2.30", 60tpi, EXO, Tubeless Ready, folding
Brakes
Brakes
Shimano MT200, 180mm rotors
Brake Levers
Shimano MT201
Cockpit
Stem
Race Face Ride, alloy, +6° rise
Handlebar
Race Face Ride Riser Bar, alloy, 10mm rise, 760mm
Grips
WTB Waffel, Lock on
Headset
FSA 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
WTB Volt Comp
Seatpost
KS Rage-i dropper, 31.6mm, 15" - 125mm travel, 17, 19, 21" - 150mm travel, Westy Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.32 mm | 1.29 mm | 1.25 mm | 1.22 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 747 mm | 771 mm | 795 mm | 820 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 121 mm | 121 mm | 121 mm | 121 mm |
| Stack | 592 mm | 601.2 mm | 610.3 mm | 619.4 mm |
| Reach | 447 mm | 467 mm | 487 mm | 507 mm |
| Top Tube Length | 595.4 mm | 623.2 mm | 651.3 mm | 673.8 mm |
| Seat Tube Angle | 76 ° | 75.5 ° | 75 ° | 75 ° |
| Seat Tube Length | 380 mm | 420 mm | 458 mm | 495 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1173 mm | 1197 mm | 1221 mm | 1245 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm | 32 mm |
| Standover Height | 739 mm | 751 mm | 754 mm | 768 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 157 cm | 168 cm | 174 cm | 173 cm |
| Rider Max Height | 170 cm | 176 cm | 185 cm | 195 cm |
Model Overview
Rakan 29 1.5 belongs to the Fuji Rakan model. Fuji released 37 bikes variations of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Fuji Rakan 29 1.5 2020 is the most economical model, with a starting price of 2099$. Fuji Rakan 29 1.1 2020 on the other hand costs 3499$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Fuji released this model in 2020, its price was 2099$. Comparing the average cost of a Trail bike to this one, you will see that Rakan 29 1.5 price is 31.59% smaller.
Rakan 29 1.5 components
Fork
This bike has the RockShox Recon Silver RL fork installed. The fork’s travel is 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Rear Shock
As for the rear shock, this bike has the RockShox Deluxe Select R model, with a travel of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The Rakan 29 1.5 2020 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 157 cm – 195 cm (5.15 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Fuji Rakan 29 1.5 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
