Fuji Rakan 29 3.5 2017
2017 Mountain
Estimate price |
3,149$
Weight | 14.26 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Rhythm Float 34
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL custom-butted alloy front and rear triangle w/ shaped oversized down tube, smooth welds, hydroformed top tube, tapered 1 1/8" - 1.5" head tube, PF30 bottom bracket, sealed cartridge bearing pivots, w/ MLink patented suspension system, 148x12mm dropout, replaceable hanger, 120mm travel
Suspension Fork
Fox Rhythm 34 Float 29, GRIP, 2-position w/ remote lockout, tapered alloy steerer, Boost 110x15mm thru axle, 120mm travel
Rear Shock
Fox Float EVOL Performance 3-position
Drivetrain
Rear Derailleur
Shimano Deore XT shadow plus, 11-speed
Front Derailleur
Shimano SLX, side swing, direct-mount
Shift Levers
Shimano SLX Ispec, Rapid Fire, 22-speed
Cassette
Shimano SLX, 11-42T, 11-speed
Crank
Shimano MT700, Hollowtech II w/ integrated spindle, 36/22T
Bottom Bracket
Shimano sealed cartridge, PF30 adaptor included
Chain
KMC X11 w/ Missing Link, 11-speed
Wheels
Rims
Oval Concepts 600AM Boost, Centerlock hubs, 110x15mm & 148x12mm thru axles, 29" 28H rims
Tires
Schwalbe Nobby Nic Performance, 29" x 2.35" 67tpi, folding
Brakes
Brakes
TRP Slate T4, hydraulic disc, 180mm rotors
Brake Levers
TRP Slate T4, hydraulic disc
Cockpit
Stem
Oval Concepts 313, 3D-forged 6061 stem body, +/-7°
Handlebar
Oval Concepts 250 riser bar, 6061 alloy, +/- 5mm rise, 9° sweep, 31.8mm clamp
Grips
Oval Concepts 620, ergo shape, single lock on, single density Kraton
Headset
FSA NO. 9M/12B, 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Oval Concepts 200, steel rail
Seatpost
Oval Concepts 300, 6061 alloy, 30.9mm diameter
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.45 mm | 1.41 mm | 1.33 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 663 mm | 698 mm | 721 mm | 750 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 89 mm | 89 mm | 89 mm | 89 mm |
| Stack | 609.5 mm | 609.5 mm | 618.2 mm | 619.5 mm |
| Reach | 384 mm | 419 mm | 438.4 mm | 467.4 mm |
| Top Tube Length | 553.5 mm | 588.5 mm | 610.5 mm | 639.5 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 381.5 mm | 432.2 mm | 482.9 mm | 533.6 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 105 mm | 105 mm | 115 mm | 115 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1109 mm | 1144 mm | 1167 mm | 1196 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm | 32 mm |
| Standover Height | 764 mm | 774 mm | 774 mm | 791 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Rakan 29 3.5 completes the Fuji Rakan model. There are 37 bikes that carry this model name. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Fuji Rakan 29 3.7 2017 is the most economical model, with a starting price of 2099$. Fuji Rakan 27.5+ 3.1 2017 on the other hand costs 4999$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3149$. In conclusion, this bike price is 14.01% more expensive than the price of the average Trail bike.
Average weight for Trail bikes
The average weight for Trail bikes is 12.98 kg (28.62 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 14.26 kg (31.44 lbs), the Rakan 29 3.5 model is a bit heavier than average. To sum up, it’s 9.86% heavier than the average weight of Trail bikes.
Rakan 29 3.5 components
Fork
This bike has the Fox Rhythm Float 34 fork installed. The fork’s travel is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
When it comes to the fork, this bike has an aluminum one, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Rear Shock
Fuji Rakan 29 3.5 bike has the Fox Float EVOL Performance 3-position model installed, and has a travel of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The wheels on Rakan 29 3.5 are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Rakan 29 3.5 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
