Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox ZEB Select
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 170cm
MD
168cm - 178cm
LG
175cm - 183cm
XL
180cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL super-butted alloy front and rear triangle, Enduro Max sealed cartridge bearings, MLink patented suspension system, Boost 148x12mm, 150mm
Suspension Fork
RockShox ZEB Select+ 29 DebonAir, tapered alloy steerer, Boost 110x15mm, 160mm
Rear Shock
RockShox Super Deluxe Coil Select+
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle, 1 x 12-speed
Cassette
SRAM XG-1275, 10-52T
Crank
Truvativ Descendant, 32T
Bottom Bracket
SRAM DUB, threaded
Chain
SRAM GX Eagle
Wheels
Rims
DT Swiss M1900 Spline 30 wheelset, 28H
Tires
Maxxis Assegai, 29" x 2.50" WT, 3C Maxx Terra, EXO+, 120tpi, Tubeless Ready, folding, Maxxis Minion DHR II, 29" x 2.40" WT, 3C Maxx Terra, EXO+, 120tpi, Tubeless Ready, folding
Brakes
Brakes
TRP Quadiem, 203/180mm rotors
Brake Levers
TRP Quadiem
Cockpit
Stem
Race Face Aeffect R, alloy, +0° rise
Handlebar
Race Face Aeffect R Riser Bar, alloy, 20mm rise, 780mm
Grips
Ergon GA20, Lock on
Headset
FSA 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Fizik Alpaca Terra X5
Seatpost
Crankbrothers Highline 3 dropper, 31.6mm, 15" - 125mm travel, 17, 19"- 150mm travel, 21" - 170mm travel, Highline Premium Ball Socket Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.31 mm | 1.27 mm | 1.24 mm |
| Bottom Bracket Height | 347 mm | 347 mm | 347 mm | 347 mm |
| Front Center | 783 mm | 807 mm | 832 mm | 856 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 138 mm | 138 mm | 138 mm | 138 mm |
| Stack | 601.6 mm | 610.5 mm | 619.5 mm | 628.5 mm |
| Reach | 447 mm | 467 mm | 487 mm | 507 mm |
| Top Tube Length | 581 mm | 608.6 mm | 636.4 mm | 658.6 mm |
| Seat Tube Angle | 77.5 ° | 77 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 380 mm | 420 mm | 458 mm | 495 mm |
| Head Tube Angle | 63.7 ° | 63.7 ° | 63.7 ° | 63.7 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1214 mm | 1238 mm | 1263 mm | 1287 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm | 27 mm |
| Standover Height | 796 mm | 792 mm | 798 mm | 804 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 168 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 178 cm | 183 cm | 188 cm |
Model Overview
Rakan 29 LT 1.1 is a Fuji Rakan model. Fuji released 37 bikes variations of this model so far. Take a sneak peek at all Fuji Rakan bikes models from 2022, by clicking here.
Model range prices
Fuji Rakan 29 1.7 2022 is the cheapest bike model and costs 1999$. Fuji Rakan LT Carbon 1.1 2022 is the most expensive one and costs 5839$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro bikes
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2022 for 4999$. If we compare this with the average Enduro bike cost we notice that the price is 38.9% more expensive.
Rakan 29 LT 1.1 components
Fork
This bike has the RockShox ZEB Select fork installed. The fork’s travel is 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Rear Shock
The shock that’s installed on this bike is RockShox Super Deluxe Coil Select+, with a travel distance of 150mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The wheels on Rakan 29 LT 1.1 are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Rakan 29 LT 1.1 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Fuji Rakan 29 LT 1.1 bike has 4 sizes, in the range of 160 cm – 188 cm (5.25 ft – 6.17 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the Rakan 29 LT 1.1. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
