Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 140mm -
Fork RockShox Revelation RC
-
Groupset X0, X9 -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A-6 Quaternary phase alloy, custom butted, integrated head tube, top tube/seat tube gusset, down tube gusset, CNC'D hollow box section BB, water bottle mount
Suspension Fork
Rock Shox Revelation 426 Dual Air w/MC 140mm travel
Rear Shock
Rock Shox Monarch 3.3 w/Motion Control, 3 Position switch Lock Out
Drivetrain
Rear Derailleur
SRAM X.0 Long cage
Front Derailleur
SRAM X.9 High Mount, 34.9mm, dual pull
Shift Levers
SRAM X.0 Trigger 27-speed
Cassette
SRAM PG-990, 11-34T 9-speed
Crank
TruVativ Stylo 3.3 Team GXP w/ Integrated BB Spindle, 22/32/44T
Bottom Bracket
TruVativ GXP Exterior Cartridge Bearing System
Chain
SRAM PC-971
Pedals
none
Wheels
Rims
Mavic Crossmax ST Disc Tubeless
Tires
Schwalbe Nobby Nic UST 26 X 2.25" Foldable
Brakes
Brakes
Avid Juicy Carbon Hydraulic Disc, 185mm Rotor
Brake Levers
Avid Juicy Carbon Hydraulic Disc
Cockpit
Stem
TruVativ Team Forged AL, 1 1/8"X 31.8mm
Handlebar
TruVativ Team Alloy Riser
Headset
Ritchey Logic Zero Pro 1 1/8" Press Fit Integrated, 30mm spacers
Seat
Saddle
Fizik Gobi w/Kium rails
Seatpost
TruVativ Team DC Forged Al, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 43.1cm | 48.2cm | 53.3cm |
|---|---|---|---|
| Bottom Bracket Height | 322.8 mm | 322.8 mm | 322.8 mm |
| Front Center | 657 mm | 682 mm | 703 mm |
| Rake | 39 mm | 39 mm | 39 mm |
| Top Tube Length | 582 mm | 607 mm | 627 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 431 mm | 482 mm | 533 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 125 mm | 130 mm | 140 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1088 mm | 1113 mm | 1134 mm |
| Bottom Bracket Drop | 11 mm | 11 mm | 11 mm |
| Standover Height | 783 mm | 799 mm | 821 mm |
| Wheels | 26" | 26" | 26" |
Model Overview
Reveal 1.0 completes the Fuji Reveal model. Fuji released 40 bikes variations of this model so far. Take a sneak peek at all Fuji Reveal bikes models from 2009, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Trail bikes
On a deeper look, we notice that the average weight of a Trail bike is 12.98 kg (28.62 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Reveal 1.0 weighs 12.51 kg (27.58 lbs) and is slightly lighter than the average. In conclusion, the average Trail bike weighs 3.76% more than Reveal 1.0.
Reveal 1.0 components
Fork
Fuji Reveal 1.0 2009 bike is equipped with the RockShox Revelation RC fork, and has 140mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When leaving the production line, the Reveal 1.0 model has 26″ aluminum wheels. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Reveal 1.0 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
