Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 130mm -
Fork RockShox Recon Silver RL
-
Groupset SLX -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A-6 Quaternary phase custom butted alloy, integrated head tube, top tube/seat tube gusset, down tube gusset, EHBT(Engineered Hollow Box Technology), water bottle mount
Suspension Fork
Rock Shox Recon 335 Solo Air w/PopLoc Remote & 130mm Travel
Rear Shock
Rock Shox Ario 3.2 w/ 2 Position switch Lock Out
Drivetrain
Rear Derailleur
Shimano SLX Shadow Top normal
Front Derailleur
Shimano SLX, 34.9mm
Shift Levers
Shimano SLX Rapid Fire, 27-speed
Cassette
Shimano HG-50, 11-34T 9-speed
Crank
Shimano SLX Hollow Tech II w/Integrated spindle, 22/32/44T
Bottom Bracket
Shimano Exterior Bearing System
Chain
Shimano HG-73
Pedals
none
Wheels
Front Hub
Shimano HB-M495 Sealed Bearing CenterLock, 32H
Rear Hub
Shimano FH-M495 Sealed Bearing CenterLock, 32H
Rims
Mavic XM-317 Disc Double Wall
Spokes
14G Stainless Steel
Tires
Schwalbe Rocket Ron, 26 X 2.25" Foldable
Brakes
Brakes
Shimano SLX Hydraulic Disc, 180mm Centerlock rotor
Brake Levers
Shimano SLX Forged AL
Cockpit
Stem
Fuji CGC Forged AL 1 1/8"
Handlebar
Fuji CGC Alloy 15mm Riser
Headset
VP A-42E 1 1/8" Press Fit Integrated, 30mm spacers
Seat
Saddle
WTB Silverado Comp
Seatpost
Fuji CGC Forged Al, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 322.8 mm | 322.8 mm | 322.8 mm |
| Front Center | 657 mm | 682 mm | 703 mm |
| Rake | 39 mm | 39 mm | 39 mm |
| Top Tube Length | 582 mm | 607 mm | 627 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 431 mm | 482 mm | 533 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 125 mm | 130 mm | 140 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1088 mm | 1113 mm | 1134 mm |
| Bottom Bracket Drop | 11 mm | 11 mm | 11 mm |
| Standover Height | 783 mm | 799 mm | 821 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
REVEAL 2.0 belongs to the Fuji Reveal model. There are 40 bikes that carry this model name. You can get a glimpse at all models from 2010, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Trail bikes
The average weight for Trail bikes is 12.98 kg (28.62 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 13.18 kg (29.06 lbs), Fuji bike is slightly heavier than average. In other words, this model is 1.54% heavier than the average Trail bike.
REVEAL 2.0 components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The REVEAL 2.0 2010 bike is equipped with 26″ aluminum wheels when leaving the factory. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
REVEAL 2.0 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
