Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 140mm -
Fork RockShox
-
Groupset XT, Deore -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A6-SL Quaternary phase Aluminum, custom butted, integrated Tapered head tube with 1 1/2" lower bearing, hydroformed top and down tube, water bottle mount
Suspension Fork
ROCKSHOX Sector R with U Turn Alloy Taper w/15mm Thru-Axle, 140mm Travel
Rear Shock
ROCKSHOX Ario R
Drivetrain
Rear Derailleur
Shimano XT SGS Direct Mount Top normal 9sp
Front Derailleur
Shimano Deore, 34.9mm
Shift Levers
Shimano Deore Rapid Fire, 27-speed
Cassette
Shimano SLX, 11-34T 9sp
Crank
Shimano Deore M-590 w/Integrated spindle, 22/32/44T
Bottom Bracket
Shimano Press In Bearing system
Chain
Shimano HG-73
Pedals
none
Wheels
Rims
Shimano SLX Centerlock, 32H hubs 15mm front thru-axle with Alex DP17 Double Wall with CNC Sidewalls
Tires
Continental Mountain King 26x2.2" Foldable
Brakes
Brakes
Shimano M575 Hydraulic Disc, 203/180mm Centerlock rotor
Brake Levers
Shimano BL-M575 Hydraulic Forged Al Brake Lever
Cockpit
Stem
Oval M-200 RBT 6061 Alloy Stem, 31.8mm
Handlebar
Oval M-200 15mm 5sweep Double Butted 6061 Riser Bar 31.8mm
Headset
Fuji MTB 1 1/8-1 1/5" Semi-Integrated, 30mm spacers
Seat
Saddle
Oval M-200 w/CrMo Rails
Seatpost
Oval M-200 31.6x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm |
| Top Tube Length | 583 mm | 613 mm | 638 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 432 mm | 482 mm | 533 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Chainstay Length | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1103 mm | 1133 mm | 1158 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Reveal 3.0 is a Fuji Reveal model. 40 bikes variations carry this model name so far. Take a sneak peek at all Fuji Reveal bikes models from 2011, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Trail bikes average weight
Trail bikes weigh an average of 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 14.2 kg (31.31 lbs), Fuji bike is a bit heavier than average. To sum up, it’s 9.4% heavier than the average weight of Trail bikes.
Overview of components
Fork
The RockShox is included from the factory. It has a travel distance of 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
As for the wheels, Fuji Reveal 3.0 2011, has a 26″ aluminum model. These wheels give you great handling over your bike. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Reveal 3.0 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Fuji Reveal 3.0 bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
