Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL custom-butted alloy, integrated 1 1/2" lower head tube, oversized 34.9mm seat tube & PIIS BB86 shell, double water bottle mounts
Suspension Fork
FC-770 carbon fork blades, w/ tapered alloy steerer
Drivetrain
Rear Derailleur
Shimano Ultegra, 10-speed
Front Derailleur
Shimano 105, band-type 34.9mm
Shift Levers
Shimano Ultegra STI shifter/brake combo, Flight Deck-compatible, 20-speed
Cassette
Shimano 105, 11-28T, 10-speed
Crank
Oval 520 forged alloy, 50/34T
Bottom Bracket
Press-fit BB86 sealed bearing
Chain
KMC X10, 10-speed
Pedals
N/A
Wheels
Rims
Oval 327 aero alloy clincher, 20/24H precision road hubs, stainless bladed spokes
Tires
Vittoria Zaffiro Pro Slick, 60 tpi, 700c x 23mm, folding
Brakes
Brakes
Shimano 105
Brake Levers
Shimano Ultegra STI
Cockpit
Stem
Oval 313 3D-forged 6061 alloy, 31.8mm, +/- 7 degrees
Handlebar
Oval 310 butted 6061 alloy, 31.8mm
Headset
FSA Orbit C-40, 1 1/8" upper - 1 1/2" lower, integrated
Seat
Saddle
Oval R500 w/ CrMo hollow rails
Seatpost
Oval 300 alloy Two-bolt, 27.2mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD | MD/LG | LG | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.4 mm | 1.42 mm | 1.43 mm | 1.46 mm | 1.47 mm | 1.49 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 578 mm | 573 mm | 575 mm | 571 mm | 586 mm | 600 mm | 615 mm |
| Rake | 50 mm | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 63 mm | 52 mm | 50 mm | 59 mm | 52 mm | 53 mm | 53 mm |
| Stack | 496 mm | 511 mm | 523 mm | 532 mm | 555 mm | 573 mm | 593 mm |
| Reach | 363 mm | 366 mm | 369 mm | 371 mm | 380 mm | 389 mm | 398 mm |
| Top Tube Length | 492 mm | 507 mm | 522 mm | 537 mm | 552 mm | 567 mm | 582 mm |
| Seat Tube Angle | 76 ° | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm |
| Wheelbase | 970 mm | 965 mm | 967 mm | 963 mm | 978 mm | 992 mm | 1007 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 719 mm | 739 mm | 758 mm | 773 mm | 802 mm | 813 mm | 837 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Roubaix 1.1 is a Fuji Roubaix model. 76 bikes variations carry this model name so far. You can easily view all of the Fuji Roubaix bikes models from 2014, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Race bikes
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Race bikes
Race bikes have an average weight of 6.82 kg (15.04 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 8.8 kg (19.4 lbs), the Roubaix 1.1 model is much heavier than average. In short, the average Race bike weight is 29.03% lower than this one.
Roubaix 1.1 components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The Roubaix 1.1 2014 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Roubaix 1.1 comes with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
