Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset 105, Tiagra -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji Altair 2 custom butted aluminum with PowerDiamond down tube, Integrated head tube, Double water bottle mounts
Suspension Fork
FC-990 Fuji Bonded Carbon Integrated w/ 1 1/8" Cro-Mo Steerer
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
NEW Shimano Tiagra, 31.8mm
Shift Levers
NEW Shimano Tiagra shifter/brake, 18-speed Flight Deck compatible
Cassette
SRAM PG-950, 12-26T 9-speed
Crank
FSA Gossamer Compact MegaExo w/ Integrated spindle, 34/50T AL outer ring
Bottom Bracket
FSA MegaExo Exterior Bearing System
Chain
KMC HG-73
Pedals
none
Wheels
Rims
Formula CXR-6, 700c clincher
Tires
Continental UltraSport, 700 x 23c
Brakes
Brakes
Tektro 423AG Forged, Dual Pivot
Brake Levers
NEW Shimano Tiagra STI
Cockpit
Stem
Fuji Pro AL forged , +/-7 degree
Handlebar
Fuji UltraLite 6061 Double Butted, 31.8mm w/Anatomical drops
Headset
Tange IS-24 1 1/8" Integrated Road
Seat
Saddle
Fuji UltraLite Racing
Seatpost
Fuji PRO Forged Alloy, 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 577 mm | 582 mm | 576 mm | 586 mm | 595 mm | 600 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 40 mm |
| Top Tube Length | 520 mm | 535 mm | 555 mm | 565 mm | 575 mm | 595 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72 ° | 72 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 115 mm | 115 mm | 129 mm | 144 mm | 164 mm | 189 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 981 mm | 987 mm | 980 mm | 990 mm | 1000 mm | 1005 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 751 mm | 764 mm | 782 mm | 798 mm | 818 mm | 845 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
About this model
Roubaix belongs to the Fuji Roubaix model. Fuji released 76 bikes variations of this model so far. You can get a glimpse at all models from 2007, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Race bikes
If you want an acceptable Race bike you should know that the average price is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Race bikes
If we make a quick analysis of the average weight of a Race bike, we get 6.82 kg (15.04 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Roubaix weighs 9.2 kg (20.28 lbs) and is much heavier than the average. In short, the average Race bike weight is 34.9% lower than this one.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the Roubaix bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Roubaix comes with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
Sizes
Roubaix comes in 6 sizes, that range from 155 cm – 191 cm (5.09 ft – 6.27 ft). In short, you can easily find one that suits you.
