Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NEW Fuji Altair 2 custom butted aluminum, Integrated 1 1/8" head tube, Standard seat tube & BB shell, Double water bottle mounts
Suspension Fork
FC-770 Fuji Bonded Carbon Integrated w/ 1 1/8" Alloy Steerer
Drivetrain
Rear Derailleur
Shimano Sora
Front Derailleur
Shimano Sora, 31.8mm
Shift Levers
Shimano Sora shifter/brake, 18-speed
Cassette
Shimano HG-50, 11-25T 9-speed
Crank
Fuji Forged Alloy 3pc, 34/50T
Bottom Bracket
ST Sealed Bearing
Chain
KMC HG-73
Pedals
none
Wheels
Front Hub
Formula Alloy Road, 32H
Rear Hub
Formula Alloy Cassette Road, 9-speed, 32H
Rims
NEW Alex DA-13 25mm Double Wall Al, 700c clincher
Spokes
14G Stainless Steel
Tires
Vittoria Zaffiro, 700 x 23c
Brakes
Brakes
Tektro R-320 dual pivot
Brake Levers
Shimano Sora STI
Cockpit
Stem
Fuji CGC Alloy 3D forged, +/-7 degree
Handlebar
Fuji CGC Double Butted 6061, 31.8mm w/Anatomical drops
Headset
Tange IS-24 1 1/8" Integrated Road
Seat
Saddle
Fuji CGC Racing
Seatpost
Fuji CGC Butted Oversize Alloy, 250mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.37 mm | 1.35 mm | 1.38 mm | 1.4 mm | 1.43 mm | 1.48 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 576 mm | 577 mm | 582 mm | 576 mm | 586 mm | 595 mm | 600 mm |
| Rake | 45 mm | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 40 mm |
| Trail | 63.4 mm | 58 mm | 56.2 mm | 53.8 mm | 53.6 mm | 54.4 mm | 55.9 mm |
| Stack | 506 mm | 504.9 mm | 504.9 mm | 524.8 mm | 539 mm | 558 mm | 585.4 mm |
| Reach | 371 mm | 367.8 mm | 373.7 mm | 379.5 mm | 385 mm | 389 mm | 395.8 mm |
| Top Tube Length | 502 mm | 507 mm | 522 mm | 542 mm | 552 mm | 562 mm | 582 mm |
| Seat Tube Angle | 76 ° | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 115 mm | 115 mm | 115 mm | 129 mm | 144 mm | 164 mm | 189 mm |
| Chainstay Length | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm |
| Wheelbase | 968 mm | 968 mm | 974 mm | 967 mm | 977 mm | 987 mm | 992 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 724 mm | 738 mm | 751 mm | 769 mm | 785 mm | 805 mm | 832 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
ROUBAIX 3.0-USA belongs to the Fuji Roubaix model. 76 bikes variations carry this model name so far. Take a sneak peek at all Fuji Roubaix bikes models from 2010, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Race bikes
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Race bikes
On a deeper look, we notice that the average weight of a Race bike is 6.82 kg (15.04 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
much heavier than average, ROUBAIX 3.0-USA has a weight of 10.27 kg (22.64 lbs). In other words, this model is 50.59% heavier than the average Race bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When leaving the production line, the ROUBAIX 3.0-USA model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji ROUBAIX 3.0-USA has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
