Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Force, Rival -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NEW Fuji Altair 2 custom butted aluminum Integrated 1 1/4" lower head tube, BB-30 bb shell, Overlize seat tube, Double water bottle mounts
Suspension Fork
NEW FC-770 Fuji Bonded Carbon Integrated w/ 1 1/8" Alloy Steerer
Drivetrain
Rear Derailleur
SRAM Force
Front Derailleur
SRAM Rival, Braze-on
Shift Levers
SRAM Rival Carbon DoubleTap shifter/brake, 20-Speed
Cassette
SRAM PG-1070, 11-26T 10-speed
Crank
FSA Gossamer Pro BB-30 w/ Integrated spindle, 38/52T 7075 CNC AL
Bottom Bracket
FSA BB-30 Bearing System
Chain
KMC DX-10, 10-sp
Pedals
none
Wheels
Rims
Mavic Aksium, 700c clincher
Tires
Continental UltraSport, 700 x 23c Foldable
Brakes
Brakes
SRAM Rival dual pivot w/cartridge pads
Brake Levers
SRAM Rival DoubleTap
Cockpit
Stem
Fuji CGC Alloy 3D forged, +/-7 degree
Handlebar
Fuji CGC Double Butted 6061, 31.8mm w/Anatomical drops
Headset
Tange 1 1/8"U-1 1/4"L Integrated Road, with convex hollow top cap
Seat
Saddle
Fuji PGC UltraLite Racing
Seatpost
Fuji CGC Butted Oversize Alloy, 250mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | MD/LG | LG | XL | XXL |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.37 mm | 1.35 mm | 1.38 mm | 1.4 mm | 1.43 mm | 1.48 mm | 1.53 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 576 mm | 577 mm | 582 mm | 576 mm | 586 mm | 595 mm | 600 mm | 619 mm |
| Rake | 45 mm | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 40 mm | 40 mm |
| Trail | 63.4 mm | 58 mm | 56.2 mm | 53.8 mm | 53.6 mm | 54.4 mm | 55.9 mm | 55.8 mm |
| Stack | 506 mm | 504.9 mm | 504.9 mm | 524.8 mm | 539 mm | 558 mm | 585.4 mm | 619 mm |
| Reach | 371 mm | 367.8 mm | 373.7 mm | 379.5 mm | 385 mm | 389 mm | 395.8 mm | 405.3 mm |
| Top Tube Length | 502 mm | 507 mm | 522 mm | 542 mm | 552 mm | 562 mm | 582 mm | 602 mm |
| Seat Tube Angle | 76 ° | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm | 640 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° | 74 ° |
| Head Tube Length | 115 mm | 115 mm | 115 mm | 129 mm | 144 mm | 164 mm | 189 mm | 224 mm |
| Chainstay Length | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm |
| Wheelbase | 968 mm | 968 mm | 974 mm | 967 mm | 977 mm | 987 mm | 992 mm | 1011 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 724 mm | 738 mm | 751 mm | 769 mm | 785 mm | 805 mm | 832 mm | 863 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
ROUBAIX ACR 1.0 belongs to the Fuji Roubaix model. 76 bikes variations carry this model name so far. You can easily view all of the Fuji Roubaix bikes models from 2010, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When it comes to wheels, the ROUBAIX ACR 1.0 bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji ROUBAIX ACR 1.0 is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
