Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Dura-Ace, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji Altair 2 custom butted aluminum with PowerDiamond down tube, Integrated head tube, Double water bottle mounts
Suspension Fork
FC-440 Fuji Carbon Monocoque Integrated w/1 1/8" Carbon steerer
Drivetrain
Rear Derailleur
Shimano Dura Ace
Front Derailleur
Shimano Dura Ace, 31.8mm
Shift Levers
Shimano Dura Ace STI shifter/brake, 20-Speed Flight Deck compatible
Cassette
Shimano 105, 12-23T 10-speed
Crank
NEW FSA Team Issue Carbon MegaExo w/ Integrated spindle, 7075 CNC 39/53T Chainrings
Bottom Bracket
FSA MegaExo Exterior Bearing System
Chain
Shimano 105, 10-speed
Pedals
none
Wheels
Rims
Mavic Aksium Race, 700c clincher
Tires
Continental UltraSport, 700 x 23c Foldable
Brakes
Brakes
Cane Creek SCR-3 w/cartridge pads
Brake Levers
Shimano Dura Ace STI
Cockpit
Stem
FSA OS-190LX 3-D Al forged , +/-7 degree
Handlebar
FSA Carbon Pro Ergo Road, 31.8mm w/Anatomical drops carbon re-enforced alloy
Headset
Tange IS-24 1 1/8" Integrated Road, with convex hollow top cap
Seat
Saddle
Selle San Marco Ponza Racing
Seatpost
FSA Carbon Pro Carbon wrapped Al, 250mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm | 64cm |
|---|---|---|---|---|---|---|---|---|
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 576 mm | 577 mm | 582 mm | 576 mm | 586 mm | 595 mm | 600 mm | 619 mm |
| Rake | 45 mm | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 40 mm | 40 mm |
| Top Tube Length | 502 mm | 507 mm | 522 mm | 542 mm | 552 mm | 562 mm | 582 mm | 602 mm |
| Seat Tube Angle | 76 ° | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm | 640 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° | 74 ° |
| Head Tube Length | 115 mm | 115 mm | 115 mm | 129 mm | 144 mm | 164 mm | 189 mm | 224 mm |
| Chainstay Length | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm |
| Wheelbase | 968 mm | 968 mm | 974 mm | 967 mm | 977 mm | 987 mm | 992 mm | 1011 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 724 mm | 738 mm | 751 mm | 769 mm | 785 mm | 805 mm | 832 mm | 863 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Roubaix LTD is a Fuji Roubaix model. Fuji released 76 bikes variations of this model so far. You can get a glimpse at all models from 2007, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Race bikes
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When leaving the production line, the Roubaix LTD model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Roubaix LTD has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
