Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji Altair 2 custom butted aluminum with PowerDiamond down tube, Integrated head tube, Double water bottle mounts
Suspension Fork
FC-770 Fuji Bonded Carbon Integrated w/ 1 1/8" Alloy Steerer
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano 105, 31.8mm
Shift Levers
Shimano 105 shifter/brake, 20-Speed Flight Deck compatible
Cassette
Shimano 105, 11-25T 10-speed
Crank
FSA Gossamer Compact MegaExo w/ Integrated spindle, 34/50T 7075 AL rings
Bottom Bracket
FSA MegaExo Exterior Bearing System
Chain
KMC DX10
Pedals
none
Wheels
Rims
Alex ALX- 200, 700c clincher
Tires
Continental UltraSport, 700 x 23c
Brakes
Brakes
Tektro R-570 dual pivot w/cartridge pads
Brake Levers
Shimano 105 STI
Cockpit
Stem
Fuji PRO Alloy 3D forged, +/-7 degree
Handlebar
Fuji UltraLite 6061 Double Butted, 31.8mm w/Anatomical drops
Headset
Tange IS-24 1 1/8" Integrated Road
Seat
Saddle
Fuji UltraLite Racing
Seatpost
Fuji PRO Forged Alloy, 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm | 64cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.37 mm | 1.35 mm | 1.38 mm | 1.4 mm | 1.43 mm | 1.48 mm | 1.53 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 576 mm | 577 mm | 582 mm | 576 mm | 586 mm | 595 mm | 600 mm | 619 mm |
| Rake | 45 mm | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 40 mm | 40 mm |
| Trail | 63.4 mm | 58 mm | 56.2 mm | 53.8 mm | 53.6 mm | 54.4 mm | 55.9 mm | 55.8 mm |
| Stack | 506 mm | 504.9 mm | 504.9 mm | 524.8 mm | 539 mm | 558 mm | 585.4 mm | 619 mm |
| Reach | 371 mm | 367.8 mm | 373.7 mm | 379.5 mm | 385 mm | 389 mm | 395.8 mm | 405.3 mm |
| Top Tube Length | 502 mm | 507 mm | 522 mm | 542 mm | 552 mm | 562 mm | 582 mm | 602 mm |
| Seat Tube Angle | 76 ° | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm | 640 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° | 74 ° |
| Head Tube Length | 115 mm | 115 mm | 115 mm | 129 mm | 144 mm | 164 mm | 189 mm | 224 mm |
| Chainstay Length | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm |
| Wheelbase | 968 mm | 968 mm | 974 mm | 967 mm | 977 mm | 987 mm | 992 mm | 1011 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 724 mm | 738 mm | 751 mm | 769 mm | 785 mm | 805 mm | 832 mm | 863 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Roubaix Pro (US) is part of the Fuji Roubaix model. Fuji launched 76 bikes of this model so far. Check out the entire range from 2009 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Race bikes
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Race bikes average weight
Race bikes weigh an average of 6.82 kg (15.04 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 8.46 kg (18.65 lbs), Fuji bike is much heavier than average. To sum up, it’s 24.05% heavier than the average weight of Race bikes.
Roubaix Pro (US) components
Fork material
Roubaix Pro (US) has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The Roubaix Pro (US) 2009 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
