Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
XS
158cm - 167cm
SM
165cm - 173cm
MD
169cm - 180cm
LG
177cm - 186cm
XL
183cm - 191cm
XXL
186cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C-4 carbon w/UD carbon, 1 1/8" Integrated head tube, Standard BB shell, Double water bottle mounts
Suspension Fork
FC-770 Bonded Carbon Integrated w/Alloy Steerer
Drivetrain
Rear Derailleur
Shimano Ultegra, 10sp
Front Derailleur
Shimano Ultegra, F-Type-Braze On Mount
Shift Levers
Shimano Ultegra STI shifter/brake, 20-speed, Flight Deck compatible
Cassette
Shimano Ultegra 11-28T, 10sp
Crank
Shimano Ultegra Hollow Tech II, 34/50T
Bottom Bracket
Shimano Ultegra BB-6700
Chain
Shimano Ultegra, 10sp
Wheels
Rims
Oval W-524 Alloy Clincher Wheelset, 24mm rim-700c, Sealed bearings
Tires
Vittoria Zaffiro Slick, 700x23c, Wire bead
Brakes
Brakes
Oval RB-300 Alloy Dual Pivot
Brake Levers
Shimano Ultegra STI
Cockpit
Stem
Oval R-300 Alloy 31.8mm Road,+/-6 degree
Handlebar
Oval R-300 Alloy w/Shallow drops
Headset
Cane Creek 1 1/8" Cartridge Bearing w/ 20mm Resin Cone Spacer
Seat
Saddle
Oval SR-500 Sweep w/CrMo Rail
Seatpost
Oval R-300 Alloy Two bolt 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.35 mm | 1.39 mm | 1.43 mm | 1.42 mm | 1.34 mm |
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 582 mm | 585 mm | 593 mm | 599 mm | 605 mm | 644 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 73 mm | 67 mm | 65 mm | 62 mm | 71 mm | 62 mm |
| Stack | 508 mm | 521 mm | 542.5 mm | 563 mm | 576 mm | 582 mm |
| Reach | 377 mm | 385 mm | 390.7 mm | 395 mm | 406 mm | 434 mm |
| Top Tube Length | 516 mm | 530.9 mm | 551 mm | 561.2 mm | 576 mm | 606 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 530 mm | 550 mm | 580 mm |
| Head Tube Angle | 70 ° | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 120 mm | 140 mm | 160 mm | 170 mm | 180 mm |
| Chainstay Length | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 982 mm | 986 mm | 993 mm | 1000 mm | 1006 mm | 1045 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 720 mm | 740 mm | 764 mm | 789 mm | 804 mm | 823 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 165 cm | 169 cm | 177 cm | 183 cm | 186 cm |
| Rider Max Height | 167 cm | 173 cm | 180 cm | 186 cm | 191 cm | 194 cm |
About this model
SL 1.0 / Ultegra is a Fuji Sl model. 63 bikes variations carry this model name so far. You can get a glimpse at all models from 2011, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Race bikes average price
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Race bikes
The average weight for Race bikes is 6.82 kg (15.04 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
SL 1.0 / Ultegra weighs 8.4 kg (18.52 lbs) and is much heavier than the average. In conclusion, the average Race bike weighs 23.17% less than SL 1.0 / Ultegra.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The SL 1.0 / Ultegra 2011 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The SL 1.0 / Ultegra comes with Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Fuji SL 1.0 / Ultegra bike has 6 sizes, in the range of 158 cm – 194 cm (5.18 ft – 6.36 ft). In short, you can easily find one that suits you.
