Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C-10 SuperLite Monocoque High Modulus carbon with 3K, Integrated aluminum cupped head tube, Double water bottle mounts
Suspension Fork
FC-330 Fuji Carbon Monocoque Integrated 1 1/8" Carbon steerer, 350g
Drivetrain
Rear Derailleur
SRAM RED
Front Derailleur
SRAM RED Braze-on Type
Shift Levers
SRAM RED Double Tap shifter/brake, 20-speed
Cassette
SRAM RED, 11-26T 10-speed,
Crank
SRAM RED Hollow Carbon w/ Integrated Spindle, Standard 39/53T
Bottom Bracket
SRAM Exterior Bearing system
Chain
SRAM RED, 10-speed
Pedals
none
Wheels
Rims
Reynold Assualt DV, 700c carbon clincher
Tires
Continental Gran Prix 4000S 700 X 23c
Brakes
Brakes
SRAM RED dual pivot w/cartridge pads
Brake Levers
SRAM RED Double Tap
Cockpit
Stem
Ritchey WCS 4Axis Carbon Alloy Matrix, +/-6 degree
Handlebar
Ritchey WCS EVO Carbon 31.8mm Road
Headset
Cane Creek IS-8I 1 1/8" Integrated Road, with Carbon convex topcap and InterLoc spacers
Seat
Saddle
San Marco Magma MG
Seatpost
Ritchey Carbon WCS Oversize 1-Bolt, 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 47cm | 50cm | 53cm | 55cm | 58cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.35 mm | 1.39 mm | 1.43 mm | 1.42 mm | 1.34 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 582 mm | 585 mm | 593 mm | 599 mm | 605 mm | 644 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 75.9 mm | 69.5 mm | 66.3 mm | 63.2 mm | 56.9 mm | 63.2 mm |
| Stack | 508 mm | 521 mm | 542.5 mm | 563 mm | 576 mm | 582 mm |
| Reach | 377 mm | 385 mm | 390.7 mm | 395 mm | 406 mm | 434 mm |
| Top Tube Length | 516 mm | 530.9 mm | 551 mm | 561.2 mm | 576 mm | 606 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 530 mm | 550 mm | 580 mm |
| Head Tube Angle | 70 ° | 71 ° | 71.5 ° | 72 ° | 73 ° | 72 ° |
| Head Tube Length | 110 mm | 120 mm | 140 mm | 160 mm | 170 mm | 180 mm |
| Chainstay Length | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 982 mm | 986 mm | 993 mm | 1000 mm | 1006 mm | 1045 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 720 mm | 740 mm | 764 mm | 789 mm | 804 mm | 823 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
SL-1 – SRAM is part of the Fuji Sl 1 model. Fuji released 6 bikes variations of this model so far. Take a sneak peek at all Fuji Sl 1 bikes models from 2009, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Race bikes average price
If you want an acceptable Race bike you should know that the average price is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Race bikes average weight
Race bikes weigh an average of 6.82 kg (15.04 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 6.66 kg (14.68 lbs), the SL-1 – SRAM model is slightly lighter than average. In other words, this model is 2.4% lighter than the average Race bike.
SL-1 – SRAM components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When it comes to wheels, the SL-1 – SRAM bike is equipped with the 700c carbon model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji SL-1 – SRAM has Rim brakes installed. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
