Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" -
Travel Front 100mm -
Fork Fox Factory Float 32
-
Groupset XTR Di2 -
Suspension Hardtail -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C15 super-light high-modulus carbon w/ internal shift cable routing, shaped oversized ride-tuned down tube, tapered 1 1/8" - 1.5" head tube, PF30 bottom bracket
Suspension Fork
Fox 32 FLOAT 27.5 Factory FIT iRD 3-position w/ Kashima coating, electronic remote lockout, tapered alloy steerer, 15mm thru axle, 100mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XTR Di2 shadow plus, 11-speed
Front Derailleur
Shimano XTR Di2, direct mount
Shift Levers
Shimano XTR Di2, 22-speed
Cassette
Shimano XTR, 11-40T, 11-speed
Crank
Oval Concepts M620, hollow forged w/ M35 integrated spindle, 36/26T
Bottom Bracket
Praxis M35
Chain
Shimano XTR, 11-speed
Pedals
N/A
Wheels
Rims
DT Swiss XR1501 Spline One 27.5 wheelset, 28h, 15mm front, 142x12mm rear, welded rims, tubeless ready, DT Swiss Competition spokes
Tires
Schwalbe Racing Ralph Evolution, 27.5" x 2.25" 67tpi, folding
Brakes
Brakes
Shimano XTR, hydraulic disc, 180/160mm rotors
Brake Levers
Shimano XTR, hydraulic disc
Cockpit
Stem
Oval Concepts 777SL, 7050 alloy w/ titanium bolts, 31.8mm clamp diameter, 6° rise
Handlebar
Oval Concepts 800 / 815, carbon, riser, 31.8mm, 9° sweep, 15mm rise
Headset
FSA NO. 42, 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Oval Concepts 800 w/ carbon rails
Seatpost
Oval Concepts 850, carbon, 27.2mm, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.4 mm | 1.37 mm | 1.35 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 311 mm | 311 mm |
| Front Center | 639 mm | 671 mm | 690 mm | 710 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 114 mm | 83 mm | 83 mm | 83 mm |
| Stack | 590.6 mm | 590.8 mm | 600.2 mm | 609.6 mm |
| Reach | 420.2 mm | 420.8 mm | 436.9 mm | 453 mm |
| Top Tube Length | 570 mm | 602 mm | 621 mm | 640 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533.5 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1057 mm | 1090 mm | 1109 mm | 1129 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm | 44 mm |
| Standover Height | 753 mm | 787 mm | 804 mm | 833 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
SLM 27.5 1.1 completes the Fuji Slm model. There are 91 bikes that carry this model name. You can get a glimpse at all models from 2016, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Crosscountry bikes
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 9.84 kg (21.69 lbs), Fuji bike is much lighter than average. To sum up, it’s 26.02% lighter than the average weight of Crosscountry bikes.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
SLM 27.5 1.1 components
Fork
This bike has the Fox Factory Float 32 fork installed. The fork’s travel is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
When it comes to the fork, this bike has an aluminum one, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
As for the wheels, Fuji SLM 27.5 1.1 2016, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
