Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" -
Travel Front 100mm -
Fork Fox Float 32
-
Groupset X0 -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C15 super-light high-modulus carbon w/ internal shift cable routing, shaped oversized ride-tuned down tube, tapered 1 1/8" - 1.5" head tube, PF30 bottom bracket
Suspension Fork
Fox 32 FLOAT 27.5 Evolution CTD w/ remote lockout, tapered alloy steerer, 15mm thru axle, 100mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM XO, 10-speed
Front Derailleur
SRAM XO, direct-mount
Shift Levers
SRAM XO Trigger, 20-speed
Cassette
Shimano SLX, 11-36T, 10-speed
Crank
Oval Concepts M620, hollow forged w/ M35 integrated spindle, 38/26T
Bottom Bracket
Praxis M35
Chain
KMC X10 w/ MissingLink, 10-speed
Pedals
N/A
Wheels
Rims
Oval Concepts 400 CL disc wheelset, 28h, 15mm front, 142x12mm rear, cartridge bearing hubs, welded rims, stainless spokes
Tires
Schwalbe Racing Ralph, 27.5" x 2.25" 67tpi, folding, tubless ready
Brakes
Brakes
Shimano Deore XT, hydraulic disc, 180/160mm rotor
Brake Levers
Shimano Deore XT, hydraulic disc
Cockpit
Stem
Oval Concepts 713, 3D-forged 7050 alloy, 31.8mm clamp diameter, 6° rise
Handlebar
Oval Concepts 600, 7050 alloy, riser, 31.8mm, 9° sweep, 15mm rise, 680 / 710mm wide
Headset
FSA NO.42, 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Oval Concepts 400 w/ CrMo rails
Seatpost
Oval Concepts 650, 7050 alloy, 27.2mm, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.4 mm | 1.37 mm | 1.35 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 311 mm | 311 mm |
| Front Center | 639 mm | 671 mm | 690 mm | 710 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 114 mm | 83 mm | 83 mm | 83 mm |
| Stack | 590.6 mm | 590.8 mm | 600.2 mm | 609.6 mm |
| Reach | 420.2 mm | 420.8 mm | 436.9 mm | 453 mm |
| Top Tube Length | 570 mm | 602 mm | 621 mm | 640 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533.5 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1057 mm | 1090 mm | 1109 mm | 1129 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm | 44 mm |
| Standover Height | 753 mm | 787 mm | 804 mm | 833 mm |
| Wheels | 27" | 27" | 27" | 27" |
About this model
SLM 27.5 1.5 Disc is part of the Fuji Slm model. Fuji released 91 bikes variations of this model so far. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
Fuji SLM 27.5 1.5 Disc 2015 bike is equipped with the Fox Float 32 fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
When it comes to wheels, the SLM 27.5 1.5 Disc bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The SLM 27.5 1.5 Disc has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
