Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Recon Silver RL
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C5 high-modulus carbon w/ internal shift cable routing, shaped oversized ride-tuned down tube, tapered 1 1/8" - 1.5" head tube
Suspension Fork
RockShox Recon Silver 29 TK Solo Air w/ tapered alloy steerer, PopLoc remote lockout, 100mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore XT, M781 SGS Shadow top normal, 10°€speed
Front Derailleur
Shimano SLX, M671, direct-mount
Shift Levers
Shimano Deore, M591 Rapid Fire, 10-speed
Cassette
Shimano Deore HG62, 11-36T, 10-speed
Crank
Shimano Deore, M590 w/ integrated spindle, 42/32/24T
Bottom Bracket
Shimano BB91 press-fit
Chain
KMC X10, 10-speed
Pedals
N/A
Wheels
Rims
Shimano Deore M595 32H Center Lock disc hubs, Sun Inferno 25
Tires
Schwalbe Rapid Rob 29" x 2.25" folding, 67 tpi
Brakes
Brakes
Shimano M445, hydraulic disc, 180mm/160mm rotor
Brake Levers
Shimano M445, hydraulic disc
Cockpit
Stem
Oval M213, 3D-forged alloy, 31.8mm clamp diameter, 6° rise
Handlebar
Oval M250, alloy riser bar, 9° sweep, 31.8mm diameter, 710mm wide, +/- 5mm rise
Headset
FSA 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Oval M400 w/ CrMo rails
Seatpost
Oval M200, alloy double-bolt micro-adjust, 31.6mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.53 mm | 1.5 mm | 1.5 mm |
| Bottom Bracket Height | 321 mm | 321 mm | 321 mm | 321 mm |
| Front Center | 655 mm | 661 mm | 681 mm | 701 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 88 mm | 79 mm | 79 mm | 79 mm |
| Stack | 604 mm | 622.4 mm | 631.7 mm | 650.9 mm |
| Reach | 396 mm | 405.8 mm | 422.1 mm | 435 mm |
| Top Tube Length | 578.5 mm | 596.6 mm | 615.6 mm | 634.8 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 394 mm | 444.5 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 100 mm | 115 mm | 125 mm | 145 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1082 mm | 1089 mm | 1108 mm | 1128 mm |
| Bottom Bracket Drop | 53 mm | 53 mm | 53 mm | 53 mm |
| Standover Height | 777 mm | 811 mm | 834 mm | 866 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
SLM 29 2.3 D is part of the Fuji Slm model. There are 91 bikes that carry this model name. Take a sneak peek at all Fuji Slm bikes models from 2013, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Crosscountry bikes average weight
Crosscountry bikes weigh an average of 12.4 kg (27.34 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Fuji SLM 29 2.3 D it’s weighing 12.6 kg (27.78 lbs). At this weight, is slightly heavier than average. In short, the average Crosscountry bike weight is 1.61% lower than this one.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
As for the wheels, Fuji SLM 29 2.3 D 2013, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The SLM 29 2.3 D has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
