Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Manitou
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C10 super-light high-modulus carbon w/ internal shift cable routing, shaped oversized ride-tuned down tube, PF30 bottom bracket, tapered 1 1/8" - 1.5" head tube
Suspension Fork
Manitou Marvel 29 Comp TS air w/ MILO remote lockout, tapered alloy steerer, 15mm Thru axle, 100mm travel
Drivetrain
Rear Derailleur
Shimano Deore XT shadow, 10-speed
Front Derailleur
Shimano Deore, direct-mount
Shift Levers
Shimano Deore, Rapid Fire, 20/30-speed
Cassette
SunRace Driven, 11-36T, 10-speed
Crank
Oval Concepts 420, integrated spindle, 36/22T
Bottom Bracket
Praxis Works sealed cartridge
Chain
KMC X10 w/ MissingLink, 10-speed
Wheels
Rims
Vera DPD22 rim 32h, Formula DC-51 front / DHT-142 rear disc hubs, Stainless black spokes
Tires
Hutchinson Cobra, 29" x 2.2", 33tpi, folding
Brakes
Brakes
Hayes Dyno Comp, hydraulic disc, 180/160mm rotor
Brake Levers
Hayes Dyno Comp, hydraulic disc
Cockpit
Stem
Oval Concepts 313, 6061 3D-forged alloy, 31.8mm, 7° rise
Handlebar
Oval Concepts 100, 6061 alloy, flat, 31.8mm, 9° sweep, 710mm wide
Headset
FSA NO.42, 1 1/8" - 1.5", sealed bearing
Seat
Saddle
Oval Concepts 200 w/ steel rails
Seatpost
Oval Concepts 300, 6061 alloy, 31.6, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.46 mm | 1.4 mm | 1.38 mm |
| Bottom Bracket Height | 321 mm | 321 mm | 321 mm | 321 mm |
| Front Center | 663 mm | 669 mm | 688 mm | 707 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 87 mm | 81 mm | 81 mm | 81 mm |
| Stack | 591.3 mm | 610.6 mm | 613.8 mm | 624.3 mm |
| Reach | 407.8 mm | 418.4 mm | 437.4 mm | 453 mm |
| Top Tube Length | 581 mm | 598 mm | 617 mm | 636 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 394 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1081 mm | 1087 mm | 1106 mm | 1126 mm |
| Bottom Bracket Drop | 53 mm | 53 mm | 53 mm | 53 mm |
| Standover Height | 770 mm | 798 mm | 809 mm | 846 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
SLM 29 2.4 is part of the Fuji Slm model. 91 bikes variations carry this model name so far. You can get a glimpse at all models from 2014, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Crosscountry bikes
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Fuji SLM 29 2.4 it’s weighing 12.1 kg (26.68 lbs). At this weight, is slightly lighter than average. In conclusion, the average Crosscountry bike weighs 2.48% more than SLM 29 2.4.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
SLM 29 2.4 components
Fork
The Manitou is included from the factory. It has a travel distance of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
The wheels on SLM 29 2.4 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The SLM 29 2.4 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
