Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 10 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C10 ultra high-modulus carbon w/ RIB Tech, integrated head tube w/ 1 1/2" lower, integrated aero seat tube, internal cable routing, oversized PIIS BB86 shell, double water bottle mounts
Suspension Fork
FC-330 carbon monocoque w/ RIB Tech, tapered carbon steerer & carbon dropout
Drivetrain
Rear Derailleur
Shimano Ultegra Di2, 10-speed
Front Derailleur
Shimano Ultegra Di2, braze-on mount
Shift Levers
Shimano Ultegra Di2 Electronic STI shifter/brake, Flight Deck-compatible, 20-speed
Cassette
Shimano Ultegra, 11-25T, 10-speed
Crank
Rotor 3DF, 50/34T
Bottom Bracket
Rotor press-fit BB86-30 sealed bearing
Chain
KMC X10, 10-speed
Pedals
N/A
Wheels
Rims
Oval W535 alloy clincher, 35mm rim - 700c
Tires
Hutchinson Equinox II, 60 tpi, 700c x 23mm, folding
Brakes
Brakes
Shimano Ultegra
Brake Levers
Shimano Ultegra Di2 STI
Cockpit
Stem
Oval 713 3D-forged 7050 alloy, 31.8mm, +/- 6 degrees
Handlebar
Oval R910 full carbon, 31.8mm
Headset
FSA Orbit C-40, 1 1/8" upper - 1 1/2" lower, integrated
Seat
Saddle
Oval R700 w/ CrMo-Ti hollow rails
Seatpost
Oval aero carbon 290mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.39 mm | 1.38 mm | 1.4 mm | 1.42 mm | 1.39 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 574 mm | 572 mm | 579 mm | 594 mm | 608 mm | 633 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 64 mm | 64 mm | 57 mm | 58 mm | 58 mm | 64 mm |
| Stack | 515 mm | 525 mm | 537 mm | 557 mm | 576 mm | 582 mm |
| Reach | 382 mm | 377 mm | 388 mm | 398 mm | 407 mm | 420 mm |
| Top Tube Length | 519 mm | 532 mm | 547 mm | 562 mm | 577 mm | 592 mm |
| Seat Tube Angle | 75 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 521 mm | 536 mm | 547 mm | 582 mm | 605 mm | 605 mm |
| Head Tube Angle | 72 ° | 72 ° | 73 ° | 73 ° | 73 ° | 72 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 150 mm | 170 mm | 180 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 976 mm | 974 mm | 981 mm | 996 mm | 1011 mm | 1036 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 758 mm | 773 mm | 786 mm | 805 mm | 825 mm | 828 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
SST 1.3 belongs to the Fuji Sst model. 39 bikes variations carry this model name so far. Check out the entire range from 2013 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
General Road bikes average price
According to our math, the average price for a trustworthy General Road bike is 1915$. However, even though the average price of a General Road bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for General Road bikes
General Road bikes have an average weight of 9 kg (19.84 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 7.48 kg (16.49 lbs), Fuji bike is much lighter than average. In other words, this model is 20.32% lighter than the average General Road bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
SST 1.3 components
Fork material
SST 1.3 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The SST 1.3 2013 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji SST 1.3 is equipped with Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
