Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C5 high-modulus carbon w/ RIB Tech, integrated head tube w/ 1 1/2" lower, aero seat tube, internal cable routing, oversized PIIS BB86 shell, double water bottle mounts
Suspension Fork
FC-440 carbon monocoque w/ RIB Tech, tapered carbon steerer & carbon dropout
Drivetrain
Rear Derailleur
Shimano 105, 11-speed
Front Derailleur
Shimano 105, braze-on mount
Shift Levers
Shimano 105, STI, 11-speed
Cassette
Shimano 105, 11-28T, 11-speed
Crank
Oval Concepts 520, forged 6066 arms, 52/36T
Bottom Bracket
Oval Concepts, BB86 press-fit
Chain
KMC X11, 11-speed
Pedals
N/A
Wheels
Rims
Oval 327 aero alloy clincher, 20 / 24h
Tires
Vittoria Zaffiro Pro Slick, 700 x 23, 60tpi, folding
Brakes
Brakes
Shimano BR-561
Brake Levers
Shimano 105, STI
Cockpit
Stem
Oval Concepts 313, 6061 3D-forged alloy, 31.8mm, +/- 7°
Handlebar
Oval Concepts 310, butted 6061 alloy, 31.8mm
Headset
FSA, 1 1/8" upper - 1 1/2" lower, integrated
Seat
Saddle
Oval Concepts R500 w/ chromoly hollow rails
Seatpost
Oval Concepts, aero carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.39 mm | 1.38 mm | 1.4 mm | 1.42 mm | 1.39 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 574 mm | 572 mm | 579 mm | 594 mm | 608 mm | 633 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 64 mm | 64 mm | 57 mm | 58 mm | 58 mm | 64 mm |
| Stack | 515 mm | 525 mm | 537 mm | 557 mm | 576 mm | 582 mm |
| Reach | 382 mm | 377 mm | 388 mm | 398 mm | 407 mm | 420 mm |
| Top Tube Length | 519 mm | 532 mm | 547 mm | 562 mm | 577 mm | 592 mm |
| Seat Tube Angle | 75 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 521 mm | 536 mm | 547 mm | 582 mm | 605 mm | 605 mm |
| Head Tube Angle | 72 ° | 72 ° | 73 ° | 73 ° | 73 ° | 72 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 150 mm | 170 mm | 180 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 976 mm | 974 mm | 981 mm | 996 mm | 1011 mm | 1036 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 758 mm | 773 mm | 786 mm | 805 mm | 825 mm | 828 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
SST 2.3 is part of the Fuji Sst model. Fuji released 39 bikes variations of this model so far. Check out the entire range from 2015 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for General Road bikes
Our math shows that the average cost of a dependable General Road bike is 1915$. However, you could also get a good General Road bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for General Road bikes
The average weight for General Road bikes is 9 kg (19.84 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
SST 2.3 weighs 8.23 kg (18.14 lbs) and is a bit lighter than the average. In conclusion, the average General Road bike weighs 9.36% more than SST 2.3.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
SST 2.3 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The wheels on SST 2.3 are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The SST 2.3 comes with Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
