Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Travel Front 50mm -
Fork SunTour
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji Altair 1 Aluminum with PowerDiamond down tube, Integrated head tube, down tube gusset, double water bottle mounts
Suspension Fork
SR Suntour SF9-NEX4110 V2, 50mm travel
Drivetrain
Rear Derailleur
Shimano Acera RD-M360
Front Derailleur
NEW Shimano FD-M191, 31.8mm Dual Pull
Shift Levers
Shimano ST-EF50 EZ-Fire integrated shifter
Cassette
Shimano CS-HG40, 11-32T 8-speed
Crank
SR Suntour XCC-T208 forged Alloy, 28/38/48T
Bottom Bracket
Sealed Cartridge Bearing ST
Chain
KMC Z-72
Pedals
Fuji ATB w/alloy cage
Wheels
Front Hub
Formula sealed alloy, 36H QR
Rear Hub
Formula sealed alloy cassette, 36H QR
Rims
Alex, ID19 double wall alloy, CNC side wall
Spokes
14G Stainless Steel
Tires
CST Cross Fire, 700 X 38c
Brakes
Brakes
ProMax V-brake, forged alloy, linear pull
Brake Levers
Shimano ST-EF50 Integrated
Cockpit
Stem
Fuji Forged alloy, adjustable angle
Handlebar
Fuji ATB 30mm rise, alloy
Headset
1 1/8" Press Fit Semi-Integrated, 30mm spacers
Seat
Saddle
Fuji Comp MTB
Seatpost
Fuji suspension 27.2, 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 618 mm | 618 mm | 643 mm | 652 mm | 678 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 553 mm | 564 mm | 583 mm | 598 mm | 623 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 431.8 mm | 483 mm | 533.4 mm | 584.2 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 115 mm | 120 mm | 130 mm | 140 mm | 155 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1047 mm | 1047 mm | 1072 mm | 1082 mm | 1107 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 745 mm | 769 mm | 795 mm | 825 mm | 858 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
SUNFIRE 3.0-EURO is part of the Fuji Sunfire model. Fuji launched 43 bikes of this model so far. Check out the entire range from 2010 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for General Urban bikes
Our math shows that the average cost of a dependable General Urban bike is 499$. However, you could also get a good General Urban bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
General Urban bikes average weight
The average weight for General Urban bikes is 13.11 kg (28.9 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Fuji SUNFIRE 3.0-EURO it’s weighing 13.25 kg (29.21 lbs). At this weight, is slightly heavier than average. In short, the average General Urban bike weight is 1.07% lower than this one.
SUNFIRE 3.0-EURO components
Fork
Fuji SUNFIRE 3.0-EURO 2010 bike is equipped with the SunTour fork, and has 50mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The wheels on SUNFIRE 3.0-EURO are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The SUNFIRE 3.0-EURO has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
SUNFIRE 3.0-EURO comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
