Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C10 ultra high-modulus carbon w/ RIB Tech, integrated head tube w/ 1 1/2" lower, aero seat tube, internal cable routing, oversized PIIS BB86 shell, double water bottle mounts
Suspension Fork
FC-330 carbon monocoque w/ RIB Tech, tapered carbon steerer & carbon dropout
Drivetrain
Rear Derailleur
Shimano Dura Ace Di2 9070, 11-speed
Front Derailleur
Shimano Dura Ace Di2 9070, braze-on mount
Shift Levers
Shimano Dura Ace Di2 9070 STI, 22-speed
Cassette
Shimano Dura Ace 9000, 11-28T, 11-speed
Crank
Shimano Dura Ace 9000, 52/36T, 11-speed
Bottom Bracket
Shimano Dura Ace press-fit BB86 sealed bearing
Chain
Shimano Dura Ace 9000, 11-speed
Pedals
N/A
Wheels
Rims
Oval 733 aero alloy clincher, 33mm rim - 700c, tubeless ready
Tires
Vittoria Rubino Pro Slick, 150 tpi, 700c x 23mm
Brakes
Brakes
Shimano Dura Ace 9000
Brake Levers
Shimano Dura Ace STI Di2 9070
Cockpit
Stem
Oval 713 3D-forged 7050 alloy, 31.8mm, +/- 6 degrees
Handlebar
Oval R910 full carbon, 31.8mm
Headset
FSA Orbit C-40, 1 1/8" upper - 1 1/2" lower, integrated w/ carbon top cover
Seat
Saddle
Oval 700 Women's w/ CrMo Ti rails
Seatpost
Oval 905, carbon 31.6mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | XS | SM | SM/MD | MD |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.39 mm | 1.42 mm | 1.46 mm | 1.49 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 575 mm | 577 mm | 578 mm | 584 mm | 588 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 48 mm |
| Trail | 66 mm | 60 mm | 60 mm | 57 mm | 53 mm |
| Stack | 512 mm | 524 mm | 531 mm | 552 mm | 575 mm |
| Reach | 370 mm | 377 mm | 375 mm | 379 mm | 387 mm |
| Top Tube Length | 506 mm | 516 mm | 526 mm | 541 mm | 556 mm |
| Seat Tube Angle | 75 ° | 75 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 71.5 ° | 72 ° | 73 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 145 mm | 165 mm |
| Chainstay Length | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 975 mm | 977 mm | 979 mm | 985 mm | 989 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 719 mm | 740 mm | 758 mm | 781 mm | 807 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Supreme 1.1 belongs to the Fuji Supreme model. There are 49 bikes that carry this model name. You can get a glimpse at all models from 2014, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Race bikes average weight
If we make a quick analysis of the average weight of a Race bike, we get 6.82 kg (15.04 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Supreme 1.1 weighs 7.03 kg (15.5 lbs) and is slightly heavier than the average. In other words, this model is 3.08% heavier than the average Race bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the Supreme 1.1 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Supreme 1.1 is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
