Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C5 high-modulus carbon w/ RIB Tech, integrated head tube w/ 1 1/2" lower, aero seat tube, internal cable routing, oversized PIIS BB86 shell, double water bottle mounts
Suspension Fork
FC-440 carbon monocoque w/ RIB Tech, tapered carbon steerer & carbon dropout
Drivetrain
Rear Derailleur
Shimano 105, 11-speed
Front Derailleur
Shimano 105, braze-on mount
Shift Levers
Shimano 105, STI, 11-speed
Cassette
Shimano 105, 11-28T, 11-speed
Crank
Oval Concepts 520, forged 6066 arms, 50/34T
Bottom Bracket
Oval Concepts, BB86 press-fit
Chain
KMC X11 w/ Missing Link, 11-speed
Pedals
N/A
Wheels
Rims
Oval 327 aero alloy clincher, 20 / 24h
Tires
Vittoria Zaffiro Pro Slick, 700 x 25, 60tpi, folding
Brakes
Brakes
Shimano 105
Brake Levers
Shimano 105, STI
Cockpit
Stem
Oval Concepts 313, 6061 3D-forged alloy, 31.8mm, +/- 7°
Handlebar
Oval Concepts 310, butted 6061 alloy, 31.8mm
Headset
FSA, 1 1/8" upper - 1 1/2" lower, integrated
Seat
Saddle
Oval Concepts R500 woman's specific fit w/ chromoly hollow rails
Seatpost
Oval Concepts 905, carbon wrapped alloy, 31.6mm, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | XS | SM | SM/MD | MD |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.39 mm | 1.42 mm | 1.46 mm | 1.49 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 575 mm | 577 mm | 578 mm | 584 mm | 588 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 48 mm |
| Trail | 65.9 mm | 59.7 mm | 59.7 mm | 56.6 mm | 52.5 mm |
| Stack | 512 mm | 524 mm | 531 mm | 552 mm | 575 mm |
| Reach | 370 mm | 377 mm | 375 mm | 379 mm | 387 mm |
| Top Tube Length | 506 mm | 516 mm | 526 mm | 541 mm | 556 mm |
| Seat Tube Angle | 75 ° | 75 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 71.5 ° | 72 ° | 73 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 145 mm | 165 mm |
| Chainstay Length | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 975 mm | 977 mm | 979 mm | 985 mm | 989 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 719 mm | 740 mm | 758 mm | 781 mm | 807 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Supreme 2.3 completes the Fuji Supreme model. Fuji released 49 bikes variations of this model so far. Take a sneak peek at all Fuji Supreme bikes models from 2016, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Race bikes
If you want an acceptable Race bike you should know that the average price is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Race bikes
Race bikes weigh an average of 6.82 kg (15.04 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 8.38 kg (18.47 lbs), the Supreme 2.3 model is much heavier than average. In other words, this model is 22.87% heavier than the average Race bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Supreme 2.3 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The wheels on Supreme 2.3 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Supreme 2.3 has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
