Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, Tiagra -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C-4 carbon w/ Integrated head tube w/1 1/2" lower, Standard round 34.9mm seat tube, Internal cable routing, Oversized PIIS BB shell, Double water bottle mounts.
Suspension Fork
FC-440 Carbon Monocoque w/Tapered Carbon steerer & carbon drop out
Drivetrain
Rear Derailleur
Shimano 105, 10-speed
Front Derailleur
Shimano Tiagra F-Type-Braze On Mount
Shift Levers
Shimano Tiagra STI shifter/brake, 18-speed Flight Deck compatible
Cassette
Shimano Tiagra 11-25T, 9sp
Crank
Shimano Tiagra Forged 2pc, 34/50T
Bottom Bracket
Shimano Press Fit Bearing
Chain
Shimano HG-73, 9sp
Wheels
Rims
Alex ALX-200, 700c Clincher Wheelset
Tires
Vittoria Zaffiro II, 700x23c, Wire Bead
Brakes
Brakes
Oval RB-300 Alloy Dual Pivot
Brake Levers
Shimano Tiagra STI
Cockpit
Stem
Oval R-300 Alloy 31.8mm Road,+/-6 degree
Handlebar
Oval RW-300 Compact Alloy, 31.8mm
Headset
FSA No. 42 1 1/8"U - 1 1/2"L Integrated w/Alloy Top Cover
Seat
Saddle
Oval SW-500 Sweep w/ CrMo Rail
Seatpost
Oval R-300 Alloy Two bolt 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.26 mm | 1.42 mm | 1.46 mm | 1.49 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 575 mm | 578 mm | 579 mm | 585 mm | 588 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 48 mm |
| Trail | 66 mm | 43 mm | 52 mm | 57 mm | 53 mm |
| Stack | 512 mm | 473.4 mm | 531.5 mm | 552.2 mm | 575.5 mm |
| Reach | 370.4 mm | 376.9 mm | 375.4 mm | 379.2 mm | 387.3 mm |
| Top Tube Length | 506 mm | 516 mm | 526 mm | 541 mm | 556 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 72 ° | 72 ° | 73 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 145 mm | 165 mm |
| Chainstay Length | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 975 mm | 977 mm | 979 mm | 985 mm | 989 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 719 mm | 739 mm | 757 mm | 781 mm | 807 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Supreme 3.0 is part of the Fuji Supreme model. Fuji launched 49 bikes of this model so far. You can easily view all of the Fuji Supreme bikes models from 2011, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Race bikes average price
If you want an acceptable Race bike you should know that the average price is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Race bikes average weight
Race bikes weigh an average of 6.82 kg (15.04 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 8.3 kg (18.3 lbs), the Supreme 3.0 model is much heavier than average. In short, the average Race bike weight is 21.7% lower than this one.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Supreme 3.0 components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on Supreme 3.0 are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
Sizes
Supreme 3.0 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
