Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
D6 high modulus carbon w/ RIB Tech, integrated head tube w/ 1 1/2" lower, aero seat tube, internal cable routing, oversized PIIS BB-86 shell, double water bottle mounts
Suspension Fork
FC-440 carbon monocoque w/ RIB Tech, tapered carbon steerer & carbon dropout
Drivetrain
Rear Derailleur
Shimano Ultegra, 10-speed
Front Derailleur
Shimano Ultegra, braze-on mount
Shift Levers
Shimano Ultegra STI shifter/brake combo, 20-speed Flight Deck compatible
Cassette
Shimano Ultegra, 11-28T 10-speed
Crank
Rotor 3D+F, 34/50T
Bottom Bracket
Rotor Press-Fit BB86/30 sealed cartridge bearing
Chain
KMC X10 Ti-Plated, 10-speed
Wheels
Rims
Oval 330 aero alloy clincher, 30mm rims - 700c, DT Champion spokes, 20/24H, precision ground hubs
Tires
Hutchinson Equinox, 700x23c, folding
Brakes
Brakes
TRP R820 forged alloy dual pivot w/ cartridge pads
Brake Levers
Shimano Ultegra STI
Cockpit
Stem
Oval 300 3D forged 6061 alloy, 31.8mm, +/-6 degree
Handlebar
Oval 300S double-butted 6061 alloy, 31.8mm
Headset
Oval 1 1/8"U - 1 1/2"L integrated w/ alloy top cover
Seat
Saddle
Selle Italia X-1 Lady Flow w/ FeC alloy rails
Seatpost
Oval 300 alloy 2-bolt, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | XS | SM | SM/MD | MD |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.388 mm | 1.396 mm | 1.423 mm | 1.464 mm | 1.494 mm |
| Front Center | 58 mm | 58 mm | 58 mm | 58 mm | 59 mm |
| Rake | 5 mm | 5 mm | 5 mm | 5 mm | 4.8 mm |
| Trail | 114 mm | 115 mm | 115 mm | 115 mm | 117 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 460 mm | 490 mm | 510 mm | 540 mm | 560 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm | 7 mm | 7 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Supreme LTD Team Edition is part of the Fuji Supreme model. Fuji released 49 bikes variations of this model so far. You can easily view all of the Fuji Supreme bikes models from 2012, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Race bikes
If you want an acceptable Race bike you should know that the average price is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Supreme LTD Team Edition components
Fork material
Supreme LTD Team Edition has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the Supreme LTD Team Edition bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
