Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Manitou
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy w/ PowerCurve down tube, smooth welds, hydroformed top tube, tapered 1 1/8" - 1.5" head tube, BB91 bottom bracket
Suspension Fork
Manitou Marvel Expert w/ remote lockout, tapered alloy steerer, 100mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore XT shadow plus, 10-speed
Front Derailleur
Shimano SLX, 34.9mm
Shift Levers
Shimano SLX Ispec, Rapid Fire, 20/30-speed
Cassette
Shimano HG-50, 11-36T, 10-speed
Crank
Shimano SLX, hollow Tech II w/ integrated spindle, 38/24T
Bottom Bracket
Shimano, press-fit
Chain
KMC X10 w/ MissingLink, 10-speed
Pedals
N/A
Wheels
Rims
Oval Concepts 400 CL disc wheelset, 28h, cartridge bearing hubs, welded rims, stainless spokes
Tires
Schwalbe Rocket Ron, 29" x 2.25", 67tpi, folding
Brakes
Brakes
Shimano Deore, hydraulic disc, 180/160mm rotor
Brake Levers
Shimano Deore, hydraulic disc
Cockpit
Stem
Oval Concepts 713, 3D-forged 7050 alloy, 31.8mm, 6° rise
Handlebar
Oval Concepts 650, 7050 alloy, flat bar, 31.8mm, 9° sweep, +/- 5mm rise, 710mm wide
Headset
FSA NO.42, 1 1/8" - 1.5", caged bearings
Seat
Saddle
Oval Concepts 600 w/ CrMo rails
Seatpost
Oval Concepts 650, 7050 alloy, 31.6mm, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.69 mm | 1.67 mm | 1.59 mm | 1.53 mm | 1.49 mm |
| Bottom Bracket Height | 319 mm | 319 mm | 319 mm | 319 mm | 319 mm |
| Front Center | 631 mm | 641 mm | 654 mm | 681 mm | 702 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 79 mm | 74 mm | 81 mm | 79 mm | 79 mm |
| Stack | 636.2 mm | 636.2 mm | 636.5 mm | 645.7 mm | 655.1 mm |
| Reach | 376.1 mm | 381.1 mm | 401 mm | 423 mm | 440.8 mm |
| Top Tube Length | 578 mm | 588 mm | 600 mm | 628 mm | 648 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533.4 mm | 584.2 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 130 mm | 140 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1060 mm | 1070 mm | 1083 mm | 1110 mm | 1131 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 789 mm | 812 mm | 840 mm | 862 mm | 891 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
Tahoe 29 1.1 Disc belongs to the Fuji Tahoe model. Fuji launched 116 bikes of this model so far. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Crosscountry bikes average weight
If we make a quick analysis of the average weight of a Crosscountry bike, we get 12.4 kg (27.34 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
much lighter than average, Tahoe 29 1.1 Disc has a weight of 11.81 kg (26.04 lbs). To sum up, it’s 5% lighter than the average weight of Crosscountry bikes.
Overview of components
Fork
Fuji Tahoe 29 1.1 Disc 2015 bike is equipped with the Manitou fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When it comes to wheels, the Tahoe 29 1.1 Disc bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Tahoe 29 1.1 Disc is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
