Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork RockShox Recon Silver TK
-
Groupset XT -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom butted Aluminum with PowerCurve down tube, Tri shaped top tube, Oversized seat tube and Integrated tapered head tube, double water bottle mounts
Suspension Fork
ROCKSHOX Recon Silver TK Solo Air 100mm travel w/ PopLoc Remote LockOut
Rear Shock
none
Drivetrain
Rear Derailleur
Shimano XT SGS Shadow Top normal 10sp
Front Derailleur
Shimano XT, 34.9mm
Shift Levers
Shimano XT Rapid Fire, 30-speed
Cassette
Shimano SLX, 11-36T 10sp
Crank
Shimano XT w/ HollowTech II, 24/32/42T
Bottom Bracket
Sealed Cartridge Bearing ST
Chain
Shimano HG-74
Pedals
Wellgo ATB w/steel cage, toe clips and straps
Wheels
Rims
Fuji Custom 32H MTB Centerlock Disc Hubs with Alex DP17 rims, Double Wall with CNC Sidewalls
Tires
Continental Race King 26x2.2" Foldable
Brakes
Brakes
Shimano M575 Hydraulic Disc, 180/160mm Centerlock rotor
Brake Levers
Shimano BL-M575 Hydraulic Forged Al Brake Lever
Cockpit
Stem
Oval M200 RBT 6061 Alloy Stem, 31.8mm
Handlebar
Oval M200 15mm Sweep Double Butted 6061 Riser Bar 31.8mm
Headset
Fuji Custom 1 1/8" - 1 1/2" Press Fit Integrated, 30mm spacers
Seat
Saddle
Fuji MTB w/ steel rail
Seatpost
Oval M200 31.6x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Bottom Bracket Height | 296 mm | 296 mm | 296 mm | 296 mm | 296 mm |
| Top Tube Length | 541.9 mm | 578 mm | 603 mm | 628 mm | 648 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533.4 mm | 584.2 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1021 mm | 1056 mm | 1082 mm | 1107 mm | 1122 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Standover Height | 707 mm | 731 mm | 758 mm | 793 mm | 823 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Tahoe LTD is part of the Fuji Tahoe model. There are 116 bikes that carry this model name. Take a sneak peek at all Fuji Tahoe bikes models from 2011, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Tahoe LTD components
Fork
The RockShox Recon Silver TK is included from the factory. It has a travel distance of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When it comes to wheels, the Tahoe LTD bike is equipped with the 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Tahoe LTD has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Tahoe LTD comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
