Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Monocoque High Modulus C-7 carbon with 12K custom weave carbon strands, Integrated aluminum cupped head tube, Double water bottle mounts.
Suspension Fork
FC-440 Fuji Carbon Monocoque Integrated 1 1/8" Carbon steerer
Drivetrain
Rear Derailleur
Shimano Dura Ace
Front Derailleur
Shimano Dura Ace F-Type
Shift Levers
Shimano Dura Ace STI shifter/brake, 20-speed Flight Deck compatible
Cassette
Shimano Dura Ace, 12-23T 10-speed,
Crank
Shimano Dura Ace w/ Integrated Spindle, 39/53T
Bottom Bracket
Shimano Exterior Bearing system
Chain
Shimano Dura Ace 10-speed
Pedals
none
Wheels
Rims
Mavic Ksyrium SL, 700c Clincher
Tires
Vittoria Diamonte Pro 700 X 23c
Brakes
Brakes
Shimano Dura Ace
Brake Levers
Shimano Dura Ace STI shifter/brake
Cockpit
Stem
Ritchey WCS 4Axis 31.8mm, +/-6 degree
Handlebar
Ritchey Carbon WCS 31.8mm
Headset
Cane Creek IS-8I 1 1/8" Integrated, w/Carbon convex topcap and InterLoc spacers
Seat
Saddle
Selle San Marco Rever
Seatpost
Ritchey Carbon WCS 250mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 577 mm | 577 mm | 576 mm | 586 mm | 596 mm | 600 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 40 mm |
| Top Tube Length | 524.4 mm | 534.3 mm | 556 mm | 565.4 mm | 568.8 mm | 595.7 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490.2 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72 ° | 72 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 129 mm | 129 mm | 129 mm | 144 mm | 169 mm | 194 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 982 mm | 982 mm | 981 mm | 991 mm | 1000 mm | 1005 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 754 mm | 771 mm | 779 mm | 798 mm | 821 mm | 847 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
About this model
Team Issue is a Fuji Team Issue model. 11 bikes variations carry this model name so far. Check out the entire range from 2007 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for General Road bikes
Our math shows that the average cost of a dependable General Road bike is 1915$. However, you could also get a good General Road bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
General Road bikes average weight
General Road bikes have an average weight of 9 kg (19.84 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Fuji Team Issue it’s weighing 7.1 kg (15.65 lbs). At this weight, is much lighter than average. In short, the average General Road bike weight is 26.76% higher than this one.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When it comes to wheels, the Team Issue bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Team Issue comes in 6 sizes, that range from 155 cm – 191 cm (5.09 ft – 6.27 ft). In conclusion, finding one for you shouldn’t be a problem.
