Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Alivio -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 520 chromoly, rack & fender mounts, pump peg & chain hanger
Suspension Fork
Chromoly w/ 1 1/8" steerer, low-rider water bottle and rack mounts
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
Shimano Alivio, 28.6mm clamp
Shift Levers
Shimano Alivio Rapidfire
Cassette
Shimano HG200, 11-34T, 9-speed
Crank
Shimano Alivio, 48/36/26T
Bottom Bracket
Shimano sealed cartridge bearing
Chain
KMC X9
Pedals
Alloy platform
Wheels
Rims
Alex double wall, 36h, Shimano hubs
Tires
Vittoria Randonneur, 700 x 40c
Brakes
Brakes
Shimano Alivio linear pull
Brake Levers
Tektro RL520
Cockpit
Stem
3D-forged 6061, +/-6°
Handlebar
Alloy, 18mm rise, 6° backsweep
Grips
Selle San Marco Presa XC
Headset
FSA, 1 1/8", sealed
Seat
Saddle
Fuji Road
Seatpost
6061 alloy, 27.2mm diameter
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL | XXXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.48 mm | 1.59 mm | 1.6 mm | 1.61 mm | 1.62 mm | 1.64 mm |
| Bottom Bracket Height | 258 mm | 258 mm | 258 mm | 258 mm | 258 mm | 258 mm | 258 mm |
| Front Center | 610 mm | 610 mm | 610 mm | 617 mm | 632 mm | 648 mm | 661 mm |
| Rake | 52 mm | 52 mm | 52 mm | 52 mm | 52 mm | 52 mm | 52 mm |
| Trail | 61 mm | 61 mm | 62 mm | 62 mm | 63 mm | 65 mm | 66 mm |
| Stack | 548 mm | 560 mm | 581 mm | 600 mm | 619 mm | 637 mm | 656 mm |
| Reach | 376 mm | 378 mm | 366 mm | 376 mm | 385 mm | 394 mm | 401 mm |
| Top Tube Length | 534 mm | 539 mm | 544 mm | 554 mm | 574 mm | 589 mm | 609 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 490 mm | 510 mm | 530 mm | 550 mm | 580 mm | 610 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 110 mm | 120 mm | 140 mm | 160 mm | 180 mm | 200 mm | 220 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm | 449 mm | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1047 mm | 1047 mm | 1047 mm | 1054 mm | 1069 mm | 1085 mm | 1099 mm |
| Bottom Bracket Drop | 78 mm | 78 mm | 78 mm | 78 mm | 78 mm | 78 mm | 78 mm |
| Standover Height | 755 mm | 780 mm | 802 mm | 823 mm | 837 mm | 861 mm | 887 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Touring LTD is part of the Fuji Touring model. Fuji released 25 bikes variations of this model so far. Take a sneak peek at all Fuji Touring bikes models from 2022, by clicking here.
Model range prices
Fuji Touring 2022 is the most affordable bike of this model and has a price of 952$. On the other hand, Fuji Touring Disc LTD 2022, is the most expensive and costs 1539$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Touring bikes average price
If you want an acceptable Touring bike you should know that the average price is 1007$. However, even if your budget is less than the average, you might still be able to get a top-quality Touring bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Fuji Touring LTD price was 1061$. If we compare this with the average Touring bike cost we notice that the price is 5.36% more expensive.
Touring LTD components
Fork material
The fork is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
As for the wheels, Fuji Touring LTD 2022, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Touring LTD has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
