Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Monocoque High Modulus C-7 carbon with 12K custom weave carbon strands, Integrated aluminum cupped head tube, Double water bottle mounts.
Suspension Fork
FC-440 Fuji Carbon Monocoque Integrated 1 1/8" Carbon steerer
Drivetrain
Rear Derailleur
Shimano Dura Ace
Front Derailleur
Shimano Dura Ace F-Type
Shift Levers
Shimano Dura Ace STI shifter/brake, 20-speed Flight Deck compatible
Cassette
Shimano Dura Ace, 12-23T 10-speed,
Crank
Shimano Dura Ace w/ Integrated Spindle, 39/53T
Bottom Bracket
Shimano Exterior Bearing system
Chain
Shimano Dura Ace 10-speed
Pedals
none
Wheels
Rims
Bontrager X-Lite Aero Aluminum, 700c Clincher
Tires
Michelin Pro2 clincher, 700 X 23c
Brakes
Brakes
Shimano Dura Ace dual pivot w/cartridge pads
Brake Levers
Shimano Dura Ace STI
Cockpit
Stem
Bontrager Race X-Lite OS CNC 31.8mm, +/-7 degree
Handlebar
Bontrager Race X-Lite OS Carbon 31.8mm
Headset
Cane Creek IS-8I 1 1/8" Integrated, w/Carbon convex topcap and InterLoc spacers
Seat
Saddle
Fizik Airone Ti
Seatpost
Bontrager Race X-Lite ACC 250mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 577 mm | 577 mm | 576 mm | 586 mm | 596 mm | 600 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 40 mm |
| Top Tube Length | 524.4 mm | 534.3 mm | 556 mm | 565.4 mm | 568.8 mm | 595.7 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490.2 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72 ° | 72 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 129 mm | 129 mm | 129 mm | 144 mm | 169 mm | 194 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 982 mm | 982 mm | 981 mm | 991 mm | 1000 mm | 1005 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 754 mm | 771 mm | 779 mm | 798 mm | 821 mm | 847 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
Model Overview
Toyota-United Team Issue (US) belongs to the Fuji Toyota United model. There are 3 bikes that carry this model name. Take a sneak peek at all Fuji Toyota United bikes models from 2008, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for General Road bikes
Our math shows that the average cost of a dependable General Road bike is 1915$. However, even though the average price of a General Road bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for General Road bikes
If we make a quick analysis of the average weight of a General Road bike, we get 9 kg (19.84 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Toyota-United Team Issue (US) weighs 7.2 kg (15.87 lbs) and is much lighter than the average. To sum up, it’s 25% lighter than the average weight of General Road bikes.
Toyota-United Team Issue (US) components
Fork material
Toyota-United Team Issue (US) has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When it comes to wheels, the Toyota-United Team Issue (US) bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Toyota-United Team Issue (US) has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Toyota-United Team Issue (US) comes in 6 sizes, that range from 155 cm – 191 cm (5.09 ft – 6.27 ft). In short, you can easily find one that suits you.
