Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Suspension Rigid -
Drivetrain Single Speed
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A6-SL custom-butted alloy w/ aero shaped down tube, hydroformed top tube, integrated head tube
Suspension Fork
FC-770 straight blade integrated carbon w/ 1 1/8" carbon steerer
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Fuji 15T CNC sprocket w/ lockring
Crank
Fuji PGC forged alloy track 2-piece, 144 bolt pattern, 48T
Bottom Bracket
Fuji PGC exterior sealed bearing system
Chain
KMC K-710SL
Wheels
Rims
Fuji PGC 30mm aero alloy, w/flip flop hubs
Tires
Hutchinson Equinox, 700x23c, folding
Brakes
Brakes
N/A
Brake Levers
N/A
Cockpit
Stem
Oval 300 3D forged 6061 alloy, 31.8mm, +/-6 degree
Handlebar
Fuji CGC track alloy, 31.8mm
Headset
1 1/8" Campy System w/ alloy top cover
Seat
Saddle
Selle Italia XR w/ FeC alloy rails
Seatpost
Fuji carbon w/ alloy clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.25 mm | 1.21 mm | 1.24 mm | 1.24 mm | 1.26 mm | 1.27 mm |
| Front Center | 55 mm | 56 mm | 57 mm | 59 mm | 60 mm | 62 mm |
| Rake | 3 mm | 3 mm | 3 mm | 3 mm | 3 mm | 3 mm |
| Trail | 570 mm | 580 mm | 594 mm | 607 mm | 612 mm | 630 mm |
| Stack | 492.4 mm | 492.1 mm | 513.1 mm | 527.6 mm | 546.8 mm | 570.9 mm |
| Reach | 394.4 mm | 406.9 mm | 414.4 mm | 425.2 mm | 434.7 mm | 447.8 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74.5 ° | 74.5 ° |
| Bottom Bracket Drop | 4 mm | 4 mm | 4 mm | 4 mm | 4 mm | 4 mm |
| Standover Height | 752 mm | 771 mm | 785 mm | 801 mm | 821 mm | 844 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
About this model
Track 1.0 INTL completes the Fuji Track model. Fuji launched 75 bikes of this model so far. Take a sneak peek at all Fuji Track bikes models from 2012, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Track bikes average price
According to our calculations, the average cost of a Track bike that is reliable is 1503$. However, even though the average price of a Track bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Track 1.0 INTL components
Fork material
Track 1.0 INTL has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, Fuji Track 1.0 INTL 2012, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Sizes
Fuji Track 1.0 INTL bike has 6 sizes, in the range of 155 cm – 200 cm (5.09 ft – 6.56 ft). In short, you can easily find one that suits you.
