Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Rim
Sizing
Recommended size guide.
XS
158cm - 167cm
SM
165cm - 173cm
MD
169cm - 180cm
LG
177cm - 186cm
XL
183cm - 191cm
XXL
186cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A-6 Quaternary phase custom butted Aluminum w/Aero shaped down tube, Integrated head tube.
Suspension Fork
FC-770 Fuji Straight Blade Integrated Carbon w/1 1/8" Alloy steerer
Drivetrain
Rear Derailleur
none
Front Derailleur
none
Shift Levers
none
Cassette
Fuji 15T CNC Sprocket w/Lockring
Crank
Fuji PGC Track 2pc, 144 bolt pattern, 48T
Bottom Bracket
Fuji PGC Exterior Sealed Bearing System
Chain
KMC K-710SL 1/2"*1/8
Wheels
Rims
Oval W-530T Alloy Clincher Wheelset, w/Flip Flop Hubs - 700c
Tires
Vittoria Zaffiro Pro Slick, 700x23c, Kevlar Bead-Folding
Brakes
Brakes
Tektro R-310 Forged Alloy Rear only
Brake Levers
Tektro RL-340 Forged Alloy
Cockpit
Stem
Fuji CGC Forged Alloy 31.8mm
Handlebar
Fuji CGC Track Alloy oversize
Headset
V.P. 1 1/8" Integrated Road, with convex hollow Alloy spacer
Seat
Saddle
Oval SR-700 Sweep w/Ti rails
Seatpost
Fuji PGC Alloy clamp for IST (Integrated Seat Tube)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.29 mm | 1.26 mm | 1.25 mm | 1.23 mm | 1.18 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | 295 mm | 295 mm | 295 mm |
| Front Center | 544 mm | 560 mm | 580 mm | 591 mm | 605 mm | 625 mm |
| Rake | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm |
| Trail | 50 mm | 55 mm | 56 mm | 62 mm | 70 mm | 85 mm |
| Stack | 486 mm | 494.3 mm | 505.4 mm | 520.1 mm | 534.5 mm | 549.5 mm |
| Reach | 366.5 mm | 384.4 mm | 402.5 mm | 415.5 mm | 434 mm | 464 mm |
| Top Tube Length | 507.5 mm | 522.5 mm | 542.5 mm | 557.5 mm | 572.5 mm | 592.5 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 686.5 mm | 695.7 mm | 715 mm | 737 mm | 770 mm | 785 mm |
| Head Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 135 mm | 150 mm | 165 mm |
| Chainstay Length | 377 mm | 377 mm | 377 mm | 377 mm | 377 mm | 377 mm |
| Wheelbase | 917 mm | 932 mm | 952 mm | 964 mm | 978 mm | 998 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 765 mm | 774 mm | 784 mm | 798 mm | 812 mm | 826 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 165 cm | 169 cm | 177 cm | 183 cm | 186 cm |
| Rider Max Height | 167 cm | 173 cm | 180 cm | 186 cm | 191 cm | 194 cm |
Model Overview
Track 1.0 (USA) belongs to the Fuji Track model. There are 75 bikes that carry this model name. You can get a glimpse at all models from 2011, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Track bikes average price
Our math shows that the average cost of a dependable Track bike is 1503$. However, this doesn’t mean that if you spend less money on a Track bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Track bikes average weight
On a deeper look, we notice that the average weight of a Track bike is 7.85 kg (17.31 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Track 1.0 (USA) weighs 8 kg (17.64 lbs) and is slightly heavier than the average. In short, the average Track bike weight is 1.91% lower than this one.
Track 1.0 (USA) components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Fuji Track 1.0 (USA) 2011, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Track 1.0 (USA) has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
This bike is available in 6 sizes. They vary from 158 cm – 194 cm (5.18 ft – 6.36 ft). In conclusion, you won’t have a problem finding one that suits you.
