Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650c / 700c -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Elios 2, custom-butted Cr-Mo
Suspension Fork
Elios 2, custom-butted Cr-Mo
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
N/A
Cassette
16T fixed cog w/ lockring
Crank
Fuji, forged alloy, 46T
Bottom Bracket
FSA, sealed cartridge bearing
Chain
KMC Z510
Pedals
Aero road w/ clips and straps
Wheels
Rims
Vera Corsa DPM27, double wall, 24/28h, Formula alloy track hubs
Tires
Vera Helios, 700 x 25, 60tpi (XXS Vera Invictus 650c x 23, 30tpi)
Brakes
Brakes
Alloy dual pivot
Brake Levers
Alloy 2-finger
Cockpit
Stem
Fuji, 3D forged alloy, 26.0mm, +/- 7°
Handlebar
Fuji track, alloy 26.0mm
Headset
FSA 1 1/8" threadless
Seat
Saddle
Oval Concepts R300 w/ steel rails
Seatpost
Fuji alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XSS | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.21 mm | 1.31 mm | 1.3 mm | 1.33 mm | 1.38 mm | 1.41 mm | 1.46 mm |
| Front Center | 571 mm | 583 mm | 587 mm | 583 mm | 585 mm | 595 mm | 599 mm |
| Rake | 40 mm | 45 mm | 45 mm | 40 mm | 40 mm | 40 mm | 35 mm |
| Trail | 57 mm | 64 mm | 57 mm | 63 mm | 56 mm | 56 mm | 58 mm |
| Stack | 460 mm | 497 mm | 505 mm | 516 mm | 539 mm | 558 mm | 585 mm |
| Reach | 380 mm | 379 mm | 389 mm | 387 mm | 391 mm | 395 mm | 401 mm |
| Top Tube Length | 497 mm | 513 mm | 536 mm | 546 mm | 556 mm | 566 mm | 587 mm |
| Seat Tube Angle | 76 ° | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 430 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72 ° | 71.5 ° | 72.5 ° | 72.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 100 mm | 90 mm | 95 mm | 105 mm | 125 mm | 145 mm | 170 mm |
| Chainstay Length | 391 mm | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 960 mm | 982 mm | 986 mm | 982 mm | 984 mm | 994 mm | 998 mm |
| Bottom Bracket Drop | 33 mm | 58 mm | 58 mm | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 699 mm | 743 mm | 759 mm | 774 mm | 795 mm | 815 mm | 842 mm |
| Wheels | 650 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Track is a Fuji Track model. 75 bikes variations carry this model name so far. Check out the entire range from 2015 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Track bikes
Our math shows that the average cost of a dependable Track bike is 1503$. However, this doesn’t mean that if you spend less money on a Track bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Track bikes average weight
If we make a quick analysis of the average weight of a Track bike, we get 7.85 kg (17.31 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Fuji Track it’s weighing 9.93 kg (21.89 lbs). At this weight, is much heavier than average. In conclusion, the average Track bike weighs 26.5% less than Track.
Track components
Fork material
The fork is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
The wheels on Track are the aluminum type. The 650c wheels are smaller in diameter than 700c. However, 650c wheels have better acceleration, and can climb easier than 700c.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Track is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
