Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Rim
Sizing
Recommended size guide.
XXS
157cm - 166cm
XS
152cm - 163cm
SM
160cm - 170cm
MD
168cm - 178cm
LG
175cm - 183cm
XL
180cm - 188cm
XXL
185cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 520 Double Butted Cr-Mo
Suspension Fork
Elios 2, custom-butted Cr-Mo
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
N/A
Cassette
16T fixed cog w/ lockring
Crank
Fuji, forged alloy, 46T
Bottom Bracket
Sealed cartridge bearing
Chain
KMC Z510
Pedals
Aero road w/ clips and straps
Wheels
Rims
Vera Corsa DPM27, double wall, 24/28h, Formula alloy track hubs
Tires
Vera Helios, 700 x 25c, 60tpi (XXS Vera Invictus 650 x 23c, 30tpi)
Brakes
Brakes
Alloy dual pivot
Brake Levers
Alloy 2-finger
Cockpit
Stem
Fuji 3D-forged alloy, 26mm, +/- 7
Handlebar
Fuji Track alloy, 26mm
Headset
FSA 1 1/8" threadless
Seat
Saddle
Oval Concepts Sport, steel rail
Seatpost
Fuji alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.21 mm | 1.31 mm | 1.3 mm | 1.33 mm | 1.38 mm | 1.41 mm | 1.46 mm |
| Bottom Bracket Height | 303 mm | 278 mm | 278 mm | 278 mm | 278 mm | 278 mm | 278 mm |
| Front Center | 571 mm | 583 mm | 587 mm | 583 mm | 585 mm | 595 mm | 599 mm |
| Rake | 40 mm | 45 mm | 45 mm | 45 mm | 40 mm | 40 mm | 35 mm |
| Trail | 60.3 mm | 64.3 mm | 58.1 mm | 58.1 mm | 57.2 mm | 57.2 mm | 59.4 mm |
| Stack | 460 mm | 497 mm | 505 mm | 516 mm | 539 mm | 558 mm | 585 mm |
| Reach | 380 mm | 379 mm | 389 mm | 387 mm | 391 mm | 395 mm | 401 mm |
| Top Tube Length | 497 mm | 513 mm | 536 mm | 546 mm | 556 mm | 566 mm | 587 mm |
| Seat Tube Angle | 76 ° | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 430 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72 ° | 71.5 ° | 72.5 ° | 72.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 100 mm | 90 mm | 95 mm | 105 mm | 125 mm | 145 mm | 170 mm |
| Chainstay Length | 391 mm | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 960 mm | 982 mm | 986 mm | 982 mm | 984 mm | 994 mm | 998 mm |
| Bottom Bracket Drop | 33 mm | 58 mm | 58 mm | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 699 mm | 743 mm | 759 mm | 774 mm | 795 mm | 815 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 152 cm | 160 cm | 168 cm | 175 cm | 180 cm | 185 cm |
| Rider Max Height | 166 cm | 163 cm | 170 cm | 178 cm | 183 cm | 188 cm | 196 cm |
About this model
Track completes the Fuji Track model. There are 75 bikes that carry this model name. Take a sneak peek at all Fuji Track bikes models from 2019, by clicking here.
Model range prices
Fuji Track 2019 is the cheapest bike model and costs 489$. Fuji Track Elite 2019 is the most expensive one and costs 4199$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Track bikes average price
Our math shows that the average cost of a dependable Track bike is 1503$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Track bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 489$. Doing a quick comparison, we notice that Track price is 207.36% smaller than the average cost of a Track bike.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
When it comes to wheels, the Track bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Track has Rim brakes installed. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
This bike is available in 7 sizes. They vary from 157 cm – 196 cm (5.15 ft – 6.43 ft). In short, you can easily find one that suits you.
