Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace -
Suspension Rigid -
Drivetrain Single Speed
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C10 ultra high-modulus aero carbon tubing, integrated seat clamp, integrated head tube w/ 1 1/2" lower
Suspension Fork
FC-330 Fuji Track carbon aero monocoque w/ 1 1/8" - 1 1/2" carbon steerer
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Shimano Dura Ace, 15T
Crank
Shimano Dura Ace Track, 50T
Bottom Bracket
Shimano Dura Ace Track
Chain
KMC Z510HX
Pedals
N/A
Wheels
Rims
Oval 981T tubular track wheels
Tires
Vittoria Pista Evo CS, 320 tpi, 700c x 22mm, tubular
Brakes
Brakes
N/A
Brake Levers
N/A
Cockpit
Stem
Oval 713 3D-forged 7050 alloy, 31.8mm, +/- 6 degrees
Handlebar
3T SCATTO carbon
Headset
FSA Orbit C-40, 1 1/8" upper - 1 1/2" lower, integrated w/ carbon top cover
Seat
Saddle
Oval R900 w/ carbon rails
Seatpost
Fuji aero carbon multi-position
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.29 mm | 1.24 mm | 1.24 mm | 1.25 mm | 1.25 mm | 1.24 mm |
| Front Center | 545 mm | 560 mm | 565 mm | 580 mm | 595 mm | 615 mm |
| Rake | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm |
| Stack | 486 mm | 486 mm | 497 mm | 512 mm | 526 mm | 541 mm |
| Reach | 377 mm | 392 mm | 400 mm | 411 mm | 422 mm | 437 mm |
| Top Tube Length | 508 mm | 523 mm | 543 mm | 558 mm | 573 mm | 593 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 466 mm | 486 mm | 516 mm | 536 mm | 542 mm | 586 mm |
| Head Tube Angle | 74 ° | 74 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 125 mm | 140 mm | 155 mm |
| Chainstay Length | 376 mm | 376 mm | 376 mm | 376 mm | 376 mm | 376 mm |
| Wheelbase | 916 mm | 931 mm | 937 mm | 952 mm | 967 mm | 987 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 764 mm | 774 mm | 794 mm | 812 mm | 826 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
Model Overview
Track Elite is a Fuji Track model. 75 bikes variations carry this model name so far. You can easily view all of the Fuji Track bikes models from 2014, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Track bikes
According to our calculations, the average cost of a Track bike that is reliable is 1503$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Track bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Track bikes
Track bikes weigh an average of 7.85 kg (17.31 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Track Elite weighs 6.6 kg (14.55 lbs) and is much lighter than the average. In short, the average Track bike weight is 18.94% higher than this one.
Track Elite components
Fork material
Track Elite has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When leaving the production line, the Track Elite model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Sizes
Track Elite comes in 6 sizes, that range from 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
