Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Truvativ -
Suspension Rigid -
Drivetrain Single Speed
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C10 ultra high-modulus aero carbon tubing, integrated seat clamp, integrated head tube w/ 1 1/2" lower
Suspension Fork
FC-330 Fuji Track carbon aero monocoque w/ 1 1/8" - 1 1/2" carbon steerer
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Shimano Dura Ace, 15T
Crank
TruVativ Omnium, 48T
Bottom Bracket
SRAM/TruVativ GXP external, sealed bearing
Chain
KMC X101
Pedals
N/A
Wheels
Rims
Oval 980T full carbon tubular track wheels, 28 / 28h
Tires
Vittoria Pista Evo CS, 700 x 22, 320 tpi, tubular
Brakes
Brakes
N/A
Brake Levers
N/A
Cockpit
Stem
Oval Concepts 713, 3D-forged 7050 alloy, 31.8mm, +/- 6°
Handlebar
Oval Concepts 710, butted 7050 alloy, 31.8mm
Headset
FSA, 1 1/8" upper - 1 1/2" lower, integratedw/ carbon top cover
Seat
Saddle
Oval Concepts R900 w/ carbon rails
Seatpost
Oval Concepts, aero carbon, multi-position
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.29 mm | 1.24 mm | 1.24 mm | 1.25 mm | 1.25 mm | 1.24 mm |
| Front Center | 545 mm | 560 mm | 565 mm | 580 mm | 595 mm | 615 mm |
| Rake | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm |
| Stack | 486 mm | 486 mm | 497 mm | 512 mm | 526 mm | 541 mm |
| Reach | 377 mm | 392 mm | 400 mm | 411 mm | 422 mm | 437 mm |
| Top Tube Length | 508 mm | 523 mm | 543 mm | 558 mm | 573 mm | 593 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 466 mm | 486 mm | 516 mm | 536 mm | 542 mm | 586 mm |
| Head Tube Angle | 74 ° | 74 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 125 mm | 140 mm | 155 mm |
| Chainstay Length | 376 mm | 376 mm | 376 mm | 376 mm | 376 mm | 376 mm |
| Wheelbase | 916 mm | 931 mm | 937 mm | 952 mm | 967 mm | 987 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 764 mm | 774 mm | 794 mm | 812 mm | 826 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
About this model
Track Elite is part of the Fuji Track model. There are 75 bikes that carry this model name. You can easily view all of the Fuji Track bikes models from 2015, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Track bikes average price
Our math shows that the average cost of a dependable Track bike is 1503$. However, even though the average price of a Track bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Track bikes
The average weight for Track bikes is 7.85 kg (17.31 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Track Elite weighs 6.64 kg (14.64 lbs) and is much lighter than the average. In conclusion, the average Track bike weighs 18.22% more than Track Elite.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When it comes to wheels, the Track Elite bike is equipped with the 700c carbon model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Sizes
Fuji Track Elite bike has 6 sizes, in the range of 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
