Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C10 ultra high-modulus carbon, integrated head tube w/ 1 1/2" lower, press fit BB30, double water bottle mounts
Suspension Fork
FC-330 carbon monocoque w/ tapered carbon steerer
Drivetrain
Rear Derailleur
Shimano Dura Ace 9000, 11-speed
Front Derailleur
Shimano Dura Ace 9000, braze-on mount
Shift Levers
Shimano Dura Ace 9000, STI, 11-speed
Cassette
Shimano Dura Ace 9000, 11-25T, 11-speed
Crank
Shimano Dura Ace 9000, 52/36T
Bottom Bracket
Praxis conversion bottom bracket
Chain
Shimano Dura Ace 9000, 11-speed
Pedals
N/A
Wheels
Rims
Oval 950F carbon / alloy clincher, 18 / 24h
Tires
Vittoria Rubino Pro Slick, 700 x 23, 150 tpi, folding
Brakes
Brakes
Shimano Dura Ace 9010 direct mount
Brake Levers
Shimano Dura Ace, STI 9000
Cockpit
Stem
Oval Concepts 713, 3D-forged 7050 alloy, 31.8mm, +/- 6°
Handlebar
Oval Concepts R910, carbon, 31.8mm
Headset
FSA, 1 1/8" upper - 1 1/2" lower, integrated w/ carbon top cover
Seat
Saddle
Oval Concepts R700 w/ chromoly-Ti hollow rails
Seatpost
Transonic aero carbon, 300mm (46-52cm), 350mm (54-61cm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.29 mm | 1.31 mm | 1.39 mm | 1.43 mm | 1.42 mm | 1.42 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 585 mm | 587 mm | 601 mm | 579 mm | 591 mm | 608 mm | 627 mm |
| Rake | 52 mm | 52 mm | 52 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 62 mm | 58 mm | 58 mm | 58 mm | 55 mm | 59 mm | 59 mm |
| Stack | 501 mm | 503 mm | 522 mm | 544 mm | 563 mm | 583 mm | 602 mm |
| Reach | 383 mm | 390 mm | 398 mm | 392 mm | 395 mm | 410 mm | 424 mm |
| Top Tube Length | 511 mm | 521 mm | 536 mm | 551 mm | 566 mm | 586 mm | 606 mm |
| Seat Tube Angle | 75.5 ° | 75.25 ° | 75 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 70.75 ° | 71.5 ° | 71.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 100 mm | 100 mm | 120 mm | 135 mm | 155 mm | 175 mm | 195 mm |
| Chainstay Length | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 986 mm | 988 mm | 1002 mm | 980 mm | 992 mm | 1009 mm | 1029 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 725 mm | 743 mm | 768 mm | 788 mm | 807 mm | 826 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Transonic 1.3 completes the Fuji Transonic model. There are 58 bikes that carry this model name. Check out the entire range from 2015 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Aero bikes average price
If you want an acceptable Aero bike you should know that the average price is 4211$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Aero bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Aero bikes
If we make a quick analysis of the average weight of an Aero bike, we get 7.34 kg (16.18 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 7.34 kg (16.18 lbs), Fuji bike is equally heavier with average. To sum up, it’s 0% heavier than the average weight of Aero bikes.
Overview of components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The Transonic 1.3 2015 bike is equipped with 700c carbon wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Transonic 1.3 comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
