Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, Praxis -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
XXS
150cm - 157cm
XS
152cm - 163cm
SM
160cm - 170cm
MD
168cm - 178cm
LG
175cm - 183cm
XL
180cm - 188cm
XXL
185cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C10 high-modulus carbon, integrated and tapered head tube, PF30 BB, and oversized chainstays.
Suspension Fork
FC-440 full carbon w/ tapered carbon steerer
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
Shimano 105, braze-on mount
Shift Levers
Shimano 105 Dual Control, 11-speed
Cassette
Shimano 105, 11-30T
Crank
Oval Concepts 300, GXP spindle, Praxis rings, 52/36T
Bottom Bracket
Praxis PF30 conversion bottom bracket
Chain
KMC X11 w/ MissingLink
Pedals
N/A
Wheels
Rims
Oval Concepts 327, 700c 20/24H rims
Tires
Vittoria Zaffiro Pro, 700 x 25c, 60tpi, folding
Brakes
Brakes
Shimano 105
Brake Levers
Shimano 105
Cockpit
Stem
Oval Concepts 790 Aero, 3D-forged, -17° w/integrated computer mount
Handlebar
Oval Concepts 790 Aero aluminum, 31.8mm clamp, 125mm drop / 75mm reach
Headset
FSA Integrated 1 1/4" upper - 1 1/2" lower sealed bearing
Seat
Saddle
Oval Concepts 438, steel rail
Seatpost
Oval Concepts Transonic Aero, 300mm 46-52cm / 350mm 54-61cm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.32 mm | 1.33 mm | 1.36 mm | 1.37 mm | 1.4 mm | 1.4 mm | 1.42 mm |
| Bottom Bracket Height | 263 mm | 266 mm | 266 mm | 268 mm | 268 mm | 270 mm | 270 mm |
| Front Center | 573 mm | 582 mm | 588 mm | 589 mm | 599 mm | 615 mm | 629 mm |
| Rake | 52 mm | 52 mm | 52 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 63.7 mm | 61.2 mm | 55 mm | 60.1 mm | 58.2 mm | 58.2 mm | 58.2 mm |
| Stack | 493 mm | 506 mm | 529 mm | 547 mm | 568 mm | 582.5 mm | 602 mm |
| Reach | 373 mm | 380 mm | 388 mm | 398 mm | 405 mm | 416 mm | 424 mm |
| Top Tube Length | 506 mm | 521 mm | 543 mm | 558 mm | 571 mm | 587 mm | 606 mm |
| Seat Tube Angle | 74.75 ° | 74.3 ° | 74.2 ° | 74.2 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 440 mm | 457 mm | 484 mm | 503 mm | 520 mm | 538 mm | 567 mm |
| Head Tube Angle | 70.6 ° | 71 ° | 72 ° | 72.7 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 93 mm | 109 mm | 129 mm | 145 mm | 166 mm | 183 mm | 203 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm |
| Wheelbase | 977 mm | 988 mm | 994 mm | 995 mm | 1005 mm | 1022 mm | 1036 mm |
| Bottom Bracket Drop | 73 mm | 70 mm | 70 mm | 68 mm | 68 mm | 66 mm | 66 mm |
| Standover Height | 736 mm | 753 mm | 778 mm | 794 mm | 812 mm | 830 mm | 852 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 152 cm | 160 cm | 168 cm | 175 cm | 180 cm | 185 cm |
| Rider Max Height | 157 cm | 163 cm | 170 cm | 178 cm | 183 cm | 188 cm | 196 cm |
About this model
Transonic 2.5 Rim is part of the Fuji Transonic model. There are 58 bikes that carry this model name. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Fuji Transonic 2.5 Rim 2020 is the most affordable bike of this model and has a price of 2099$. On the other hand, Fuji Transonic 1.1 2020, is the most expensive and costs 7499$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Aero bikes
According to our math, the average price for a trustworthy Aero bike is 4211$. However, you could also get a good Aero bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Fuji Transonic 2.5 Rim price was 2099$. In conclusion, this bike price is 100.62% smaller than the price of the average Aero bike.
Overview of components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The Transonic 2.5 Rim 2020 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Transonic 2.5 Rim has Rim brakes installed. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
There are 7 sizes available for this model. Rider height can be anywhere between 150 cm – 196 cm (4.92 ft – 6.43 ft). In conclusion, finding one for you shouldn’t be a problem.
