Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A2-SL butted 6061, semi-integrated headtube, and water bottle mounts
Suspension Fork
SR Suntour NEX w/ hydrualic lockout, 63mm travel
Drivetrain
Rear Derailleur
Shimano XT, 10-speed
Front Derailleur
Shimano SLX, 34.9mm
Shift Levers
Shimano Deore 10-speed
Cassette
Shimano Deore,11-34T, 10-speed
Crank
Shimano LX, 48/36/26T
Bottom Bracket
Shimano
Chain
KMC X10, 10-speed
Pedals
Alloy body w/ alloy cage
Wheels
Rims
Formula DC-73 sealed bearing front / Shimano M475 rear, 32H disc hubs w/ Vera Terra alloy rims quick-release
Tires
Vera EOS, 700 x 38c, 30 tpi w/ Phanlanx PR
Brakes
Brakes
Hayes Dyno Sport hydraulic disc, 160mm rotor
Brake Levers
Hayes Dyno Sport hydraulic
Cockpit
Stem
Oval 213, 3D-forged alloy w/ 12 degree rise, 31.8mm
Handlebar
Oval 200M, alloy w/ 30mm rise, 31.8mm
Headset
FSA, semi-integrated
Seat
Saddle
Oval 300R
Seatpost
Oval 200M, alloy, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | SM/MD | MD/LG | LG |
|---|---|---|---|---|---|
| Bottom Bracket Height | 289 mm | 289 mm | 289 mm | 289 mm | 289 mm |
| Top Tube Length | 549 mm | 557 mm | 568 mm | 597 mm | 607 mm |
| Seat Tube Angle | 73 ° | 72 ° | 73 ° | 72 ° | 72 ° |
| Seat Tube Length | 380 mm | 482 mm | 440 mm | 520 mm | 560 mm |
| Head Tube Angle | 70 ° | 71 ° | 70 ° | 71 ° | 71 ° |
| Head Tube Length | 110 mm | 120 mm | 110 mm | 140 mm | 155 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1044 mm | 1065 mm | 1063 mm | 1077 mm | 1086 mm |
| Standover Height | 721 mm | 759 mm | 739 mm | 793 mm | 827 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Traverse 1.0 completes the Fuji Traverse model. There are 83 bikes that carry this model name. Check out the entire range from 2013 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Hybrid bikes
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Traverse 1.0 components
Fork
The SunTour NEX is included from the factory. It has a travel distance of 63mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The Traverse 1.0 2013 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Traverse 1.0 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
