Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy w/ PowerCurve down tube, 1-1/8" semi-integrated headtube
Suspension Fork
SR NEX suspension w/ hydraulic lockout, 63mm travel
Drivetrain
Rear Derailleur
Shimano Acera, 8/9-speed
Front Derailleur
Shimano Altus
Shift Levers
Shimano Altus, Rapid Fire w/ optical gear display, 8-speed
Cassette
Shimano Altus, 11-32T, 8-speed
Crank
Shimano Acera, 48/38/28T w/ chainguard
Bottom Bracket
Sealed cartridge
Chain
KMC HV700, 8-speed
Pedals
Resin platform
Wheels
Rims
Vera Terra DPD16 double wall rims 32h, alloy disc hubs, 14g spokes
Tires
Vera EOS, 700 x 38c, 30 tpi w/ Phalanx flat protection
Brakes
Brakes
Tektro hydraulic disc, 160mm/160mm rotor
Brake Levers
Tektro hydraulic disc, 2-finger
Cockpit
Stem
Oval Concepts 313, 6061 3D-forged alloy, 7° rise, 31.8mm
Handlebar
Oval Concepts 200, 6061 alloy, 15mm rise, 9° sweep, 31.8mm
Headset
FSA, 1-1/8" semi-integrated threadless
Seat
Saddle
Oval Concepts Woman's P300 w/ steel rails
Seatpost
Oval Concepts 300, 3D-forged 6061 alloy, 31.6mm, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 0.145 mm | 0.145 mm | 0.156 mm | 0.156 mm |
| Bottom Bracket Height | 289 mm | 289 mm | 289 mm | 289 mm |
| Reach | 620 mm | 620 mm | 640 mm | 640 mm |
| Top Tube Length | 567 mm | 578 mm | 585 mm | 595 mm |
| Seat Tube Angle | 73 ° | 73 ° | 72 ° | 72 ° |
| Seat Tube Length | 400 mm | 460 mm | 500 mm | 540 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° |
| Head Tube Length | 145 mm | 145 mm | 145 mm | 155 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1062 mm | 1071 mm | 1060 mm | 1070 mm |
| Standover Height | 711 mm | 736 mm | 762 mm | 781 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Traverse 1.5 Disc ST is part of the Fuji Traverse model. 83 bikes variations carry this model name so far. You can get a glimpse at all models from 2016, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Hybrid bikes
If you want to purchase a solid Hybrid bike, it is important to know that the average cost is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Hybrid bikes
If we make a quick analysis of the average weight of a Hybrid bike, we get 13.85 kg (30.53 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
slightly lighter than average, Traverse 1.5 Disc ST has a weight of 13.8 kg (30.42 lbs). In conclusion, the average Hybrid bike weighs 0.36% more than Traverse 1.5 Disc ST.
Traverse 1.5 Disc ST components
Fork
The fork installed on this bike is the SunTour NEX model. The travel on this model is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When it comes to wheels, the Traverse 1.5 Disc ST bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Traverse 1.5 Disc ST is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
