Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy w/ PowerCurve down tube, 1-1/8" semi-integrated headtube
Suspension Fork
SR NEX suspension, adjustable, 63mm travel
Drivetrain
Rear Derailleur
Shimano Altus, 7/8-speed
Front Derailleur
Shimano Tourney
Shift Levers
Shimano EF51 Altus, EZ Fire, 7-speed
Cassette
Shimano TZ31, 14-34T, 7-speed
Crank
Shimano TY701, 48/38/28T w/ chainguard
Bottom Bracket
Sealed cartridge
Chain
KMC HV500, 7-speed
Pedals
Resin platform
Wheels
Rims
Vera Terra DPD16 double wall rims 32h, alloy disc hubs, 14g spokes
Tires
Vera EOS, 700 x 38c, 30 tpi
Brakes
Brakes
Tektro mechanical disc, 160mm/160mm rotor
Brake Levers
Shimano EF51 Altus, 2-finger
Cockpit
Stem
Oval Concepts, alloy, 20° rise, 31.8mm
Handlebar
Oval Concepts, 6061 alloy, 15mm rise, 5° sweep, 31.8mm
Headset
FSA, 1-1/8" semi-integrated threadless
Seat
Saddle
Oval Concepts w/ steel rails
Seatpost
Oval Concepts, alloy, 31.6mm, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.63 mm | 1.55 mm | 1.57 mm | 1.6 mm | 1.62 mm | 1.59 mm |
| Front Center | 594 mm | 613 mm | 615 mm | 626 mm | 636 mm | 656 mm |
| Rake | 43.8 mm | 43.8 mm | 43.8 mm | 43.8 mm | 43.8 mm | 43.8 mm |
| Trail | 95 mm | 95 mm | 92 mm | 92 mm | 92 mm | 92 mm |
| Stack | 591 mm | 591 mm | 602 mm | 621 mm | 635 mm | 649 mm |
| Reach | 362 mm | 381 mm | 384 mm | 388 mm | 393 mm | 408 mm |
| Top Tube Length | 549 mm | 568 mm | 586 mm | 597 mm | 607 mm | 627 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 380 mm | 440 mm | 482 mm | 520 mm | 560 mm | 600 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 140 mm | 155 mm | 170 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1044 mm | 1063 mm | 1065 mm | 1076 mm | 1086 mm | 1106 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 732 mm | 772 mm | 789 mm | 817 mm | 842 mm | 875 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Traverse 1.7 Disc is part of the Fuji Traverse model. Fuji launched 83 bikes of this model so far. You can easily view all of the Fuji Traverse bikes models from 2016, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Hybrid bikes
If you want to purchase a solid Hybrid bike, it is important to know that the average cost is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Hybrid bikes
If we make a quick analysis of the average weight of a Hybrid bike, we get 13.85 kg (30.53 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Traverse 1.7 Disc weighs 14.17 kg (31.24 lbs) and is slightly heavier than the average. In conclusion, the average Hybrid bike weighs 2.31% less than Traverse 1.7 Disc.
Traverse 1.7 Disc components
Fork
The fork installed on this bike is the SunTour NEX model. The travel on this model is 63mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the Traverse 1.7 Disc bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Traverse 1.7 Disc has Mechanical Disc brakes installed. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
