Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XXS
157cm - 167cm
XS
165cm - 173cm
SM
171cm - 179cm
MD
177cm - 185cm
LG
183cm - 191cm
XL
188cm - 197cm
XXL
194cm - 204cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
A6-SL custom-butted alloy w/ shaped top tube & integrated tapered head tube w/ 1 1/2" lower, oversized 34.9mm round seat tube, BB86 shell, double water bottle mounts
Suspension Fork
FC-770 Disc, Carbon blades, Tapered 1 1/8" to 1.5" Alloy Steerer
Drivetrain
Rear Derailleur
Shimano Tiagra, 10-speed
Front Derailleur
Shimano Tiagra, 34.9mm clamp
Shift Levers
Shimano Tiagra, STI, 10-speed
Cassette
Shimano HG-500, 11-32T, 10-speed
Crank
Shimano Tiagra, 50/34T
Bottom Bracket
Shimano Press Fit
Chain
KMC X10 w/ MissingLink, 10-speed
Pedals
N/A
Wheels
Rims
Vera Terra DPD22 rims, 32H, stainless eyelets, alloy disc hubs
Tires
Vera CityWide, 700 x 32c, 30tpi w/ Phalanx flat protection
Brakes
Brakes
TRP Spyre, Mechanical disc, 160mm/160mm Rotors
Brake Levers
Shimano Tiagra STI
Cockpit
Stem
Oval Concepts 313, 6061 3D-forged alloy, 31.8mm, +/- 7°
Handlebar
Oval Concepts 310, 6061 alloy, 31.8mm
Headset
FSA No. 42, 1 1/8" - 1.5", integrated cartridge
Seat
Saddle
Oval Concepts 300 Pavement, steel rail
Seatpost
Oval Concepts 300, 3D-forged 6061 alloy, 27.2mm, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.4 mm | 1.46 mm | 1.52 mm | 1.53 mm | 1.53 mm | 1.55 mm |
| Front Center | 583 mm | 599 mm | 600 mm | 590 mm | 605 mm | 621 mm | 636 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 67 mm | 67 mm | 63 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Stack | 523 mm | 528 mm | 549 mm | 558 mm | 577 mm | 594 mm | 613 mm |
| Reach | 364 mm | 377 mm | 377 mm | 368 mm | 377 mm | 387 mm | 396 mm |
| Top Tube Length | 505 mm | 520 mm | 530 mm | 540 mm | 555 mm | 570 mm | 585 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 105 mm | 110 mm | 130 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 998 mm | 1014 mm | 1015 mm | 1006 mm | 1021 mm | 1038 mm | 1053 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 67 mm | 67 mm | 65 mm | 65 mm |
| Standover Height | 759 mm | 770 mm | 790 mm | 800 mm | 807 mm | 842 mm | 862 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 165 cm | 171 cm | 177 cm | 183 cm | 188 cm | 194 cm |
| Rider Max Height | 167 cm | 173 cm | 179 cm | 185 cm | 191 cm | 197 cm | 204 cm |
Model Overview
Tread 1.3 Disc belongs to the Fuji Tread model. There are 9 bikes that carry this model name. Check out the entire range from 2016 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
General Urban bikes average price
According to our calculations, the average cost of a General Urban bike that is reliable is 499$. However, even if your budget is less than the average, you might still be able to get a top-quality General Urban bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Fuji Tread 1.3 Disc 2016, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Tread 1.3 Disc has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
There are 7 sizes available for this model. Rider height can be anywhere between 157 cm – 204 cm (5.15 ft – 6.69 ft). In conclusion, it won’t take much to find one that’s right for you.
