Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL custom-butted alloy w/ integrated 1 1/8" - 1 1/2" lower tapered head tube, oversized 34.9mm seat tube, PIIS BB86 shell, double water bottle mounts
Suspension Fork
FC-770 carbon blade, alloy crown w/ tapered alloy steerer & alloy dropouts
Drivetrain
Rear Derailleur
Shimano Claris, 8-speed
Front Derailleur
Shimano Claris
Shift Levers
Shimano Claris STI, 8-speed
Cassette
Shimano Altus, 11-32T, 8-speed
Crank
Oval Concepts 520, forged 6066 arms, 50/34T
Bottom Bracket
Oval, external, sealed bearing
Chain
KMC HV700, 8-speed
Pedals
Nylon platform
Wheels
Rims
Vera Terra DPD18 rims 32h, alloy disc hubs, aero spokes
Tires
Vera CityWide, 700 x 32c, 30 tpi
Brakes
Brakes
Tektro Mira, mechanical disc, 160mm/140mm rotors
Brake Levers
Shimano Claris, STI
Cockpit
Stem
Oval Concepts, melt-forged alloy, 31.8mm, +/- 10°
Handlebar
Oval Concepts 300S, 6061 alloy, 31.8mm
Headset
FSA, 1 1/8" upper - 1 1/2" lower, integrated cartridge
Seat
Saddle
Oval Concepts w/ steel rails
Seatpost
Oval Concepts, alloy, 27.2mm, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|---|
| Front Center | 583 mm | 599 mm | 600 mm | 590 mm | 605 mm | 621 mm | 636 mm |
| Top Tube Length | 505 mm | 520 mm | 530 mm | 540 mm | 555 mm | 570 mm | 585 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 105 mm | 110 mm | 130 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 998 mm | 1014 mm | 1015 mm | 1006 mm | 1021 mm | 1038 mm | 1053 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 67 mm | 67 mm | 65 mm | 65 mm |
| Standover Height | 744 mm | 756 mm | 774 mm | 787 mm | 808 mm | 825 mm | 845 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Tread 1.5 Disc completes the Fuji Tread model. Fuji launched 9 bikes of this model so far. Check out the entire range from 2015 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for General Urban bikes
Our math shows that the average cost of a dependable General Urban bike is 499$. However, even if your budget is less than the average, you might still be able to get a top-quality General Urban bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for General Urban bikes
The average weight for General Urban bikes is 13.11 kg (28.9 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 11.28 kg (24.87 lbs), Fuji bike is much lighter than average. In other words, this model is 16.22% lighter than the average General Urban bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When it comes to wheels, the Tread 1.5 Disc bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Tread 1.5 Disc has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
