Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Groupset Altus, SLX -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL alloy w/ PowerCurve down tube, oversized seat tube
Suspension Fork
Fuji Alloy rigid, 1 1/8" threadless, disc tabs
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Altus shadow, 9-speed
Front Derailleur
Shimano SLX, 34.9mm
Shift Levers
Shimano Altus, Rapid Fire, 9-speed
Cassette
Shimano HG200-9, 11-34T, 9-speed
Crank
Samox, alloy, 44/32/22T
Bottom Bracket
Sealed cartridge bearing
Chain
KMC Z99, 9-speed
Pedals
Alloy platform
Wheels
Rims
Weinmann rims, 100mm (F), 100mm (R) wide, 32h, Formula SL-1240 front, Formula DHL-197 rear disc hubs, stainless black spokes
Tires
Vee Bulldozer, 26 X 4.7", 72tpi
Brakes
Brakes
Tektro M280, mechanical disc, 180/160mm rotors
Brake Levers
Tektro, alloy
Cockpit
Stem
Oval Concepts 313, 6061 3D-forged alloy, 31.8mm, 7° rise
Handlebar
Oval Concepts flat bar, 6061 alloy, 31.8mm, 9° sweep, 0mm rise
Headset
FSA NO. 42B, 1 1/8" semi-integrated, caged bearings
Seat
Saddle
Oval Concepts 200 w/ steel rails
Seatpost
Oval Concepts, 6061 alloy, 30.9mm, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.49 mm | 1.47 mm | 1.45 mm |
| Bottom Bracket Height | 289 mm | 289 mm | 289 mm | 289 mm |
| Front Center | 665 mm | 680 mm | 696 mm | 711 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 75 mm | 75 mm | 75 mm | 75 mm |
| Stack | 604.4 mm | 613.7 mm | 623.1 mm | 632.5 mm |
| Reach | 400.6 mm | 412.8 mm | 424.9 mm | 437 mm |
| Top Tube Length | 586 mm | 601 mm | 616 mm | 631 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 125 mm | 135 mm | 145 mm | 155 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1124 mm | 1140 mm | 1155 mm | 1171 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm | 54 mm |
| Standover Height | 795 mm | 823 mm | 852 mm | 881 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Wendigo 26 1.3 belongs to the Fuji Wendigo model. There are 8 bikes that carry this model name. You can easily view all of the Fuji Wendigo bikes models from 2016, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Fatbike bikes
If you want an acceptable Fatbike bike you should know that the average price is 1743$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fatbike bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Fatbike bikes average weight
Fatbike bikes weigh an average of 13.2 kg (29.1 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 16.57 kg (36.53 lbs), Fuji bike is much heavier than average. To sum up, it’s 25.53% heavier than the average weight of Fatbike bikes.
Wendigo 26 1.3 components
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When leaving the production line, the Wendigo 26 1.3 model has 26″ aluminum wheels. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Wendigo 26 1.3 has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
