Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tourney, Shimano -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
S-6 LT aluminum
Suspension Fork
HTS Steel
Drivetrain
Rear Derailleur
Shimano Tourney TX800, 7-speed
Front Derailleur
Shimano Tourney TY510
Shift Levers
Shimano EF500, EZ-Fire Plus
Cassette
Freewheel 14-32T, 7-speed
Crank
Prowheel TY-CQ01, 48/38/28T
Bottom Bracket
Square taper, 68 x 120 mm
Chain
KMC Z51
Pedals
Platform
Wheels
Front Hub
KT,QR 9 x 100 mm
Rear Hub
KT, freewheel, QR 10 x 135 mm
Rims
Star Circle J17, alloy, 32h
Spokes
14g, stainless steel
Tires
CST C1605, 700 x 32c
Brakes
Brakes
Radius, V-type
Brake Levers
Shimano EF500
Cockpit
Stem
Caribou Panache 3, 7 ?
Handlebar
Steel, 20 mm, Ø31.8 mm
Grips
Garneau Ergo
Headset
ZS41.4/28.6 | ZS41.4/30.0, 1 1/8''
Seat
Saddle
Royal Essenza + Athletic
Seatpost
Caribou Panache 3, Ø27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.44 mm | 1.47 mm | 1.51 mm |
| Front Center | 614 mm | 633 mm | 647 mm | 665 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 70 mm | 70 mm | 67 mm | 67 mm |
| Stack | 551 mm | 575 mm | 600 mm | 629 mm |
| Reach | 388 mm | 398 mm | 408 mm | 416 mm |
| Top Tube Length | 546 mm | 568 mm | 591 mm | 614 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 435 mm | 470 mm | 505 mm | 540 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 125 mm | 150 mm | 180 mm | 210 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1056 mm | 1075 mm | 1090 mm | 1108 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 65 mm | 65 mm |
| Standover Height | 742 mm | 769 mm | 803 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Urbania 5 is part of the Garneau Urbania model. There are 12 bikes that carry this model name. Take a sneak peek at all Garneau Urbania bikes models from 2023, by clicking here.
Model range prices
Garneau Women’s Urbania 5 Bike 2023 is the most affordable bike of this model and has a price of 498$. On the other hand, Garneau Urbania 1 2023, is the most expensive and costs 1156$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Hybrid bikes
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2023 and its price was 621$. Comparing this to the average Hybrid bike price, we see that the price is 10.5% higher.
Urbania 5 components
Fork material
The fork on this bike is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
As for the wheels, Garneau Urbania 5 2023, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Garneau Urbania 5 has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
Garneau Urbania 5 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
