Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Factory Float 38
-
Groupset GX Eagle, SRAM -
Suspension Full -
Motor Yamaha 250W 85Nm mid-drive -
Battery Simplo, 720 Wh, 36 V -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29", Alloy 6061, Integrated battery, Boost, 160 mm
Suspension Fork
FOX Float 38 Factory, Grip 2, E-Optimized, Air, 170 mm, tapered
Rear Shock
FOX Float X Factory, Air, 230x65 mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-S
Shift Levers
SRAM GX Eagle, Single Click
Cassette
SRAM PG-1230, 11-50 T
Crank
SRAM X-Sync Eagle, 38 T
Chain
SRAM GX Eagle
Chain Guide
ISCG-05
Pedals
GASGAS, aluminum
Wheels
Rims
NEWMEN Evolution A.30, Tubeless ready, Center lock, 15x110/12x148 mm, thru axle
Tires
Schwalbe Magic Mary, Evolution, 62-622, 29x2.4, Tubeless ready
Brakes
Brakes
Front: SRAM Code R, 4-piston, Hydraulic disc brake, Rear: SRAM Code R, 4-piston, Hydraulic disc brake
Cockpit
Stem
GASGAS 35, 0 °, Ahead
Handlebar
GASGAS Riser 35 mm, 780 mm, Sweep: 9 °, Rise: 20 mm
Grips
GASGAS MTB, Lock-on grips
Headset
FSA Orbit ZS56/ZS56
Seat
Saddle
GASGAS MTB
Seatpost
GASGAS, 34.9 mm, Dropper post
Motor & Battery
Motor
Yamaha PW-X3, 250 W, 85 Nm
Battery
Simplo, 720 Wh, 36 V
Charger
Simplo rapid charger, 4 A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.36 mm | 1.3 mm | 1.25 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm | 354 mm |
| Front Center | 782 mm | 799 mm | 826 mm | 854 mm |
| Rake | 39 mm | 39 mm | 39 mm | 40 mm |
| Trail | 139 mm | 139 mm | 139 mm | 138 mm |
| Stack | 613 mm | 618 mm | 622 mm | 627 mm |
| Reach | 438 mm | 453 mm | 478 mm | 503 mm |
| Top Tube Length | 499 mm | 523 mm | 554 mm | 638 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 410 mm | 440 mm | 460 mm | 490 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm | 115 mm |
| Chainstay Length | 453 mm | 453 mm | 453 mm | 453 mm |
| Wheelbase | 1234 mm | 1251 mm | 1278 mm | 1306 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
ECA 3 completes the Gasgas E Eca model. There are 2 e-bikes that carry this model name. You can easily view all of the Gasgas E Eca e-bikes models from 2023, here.
Model range prices
The most economical model, the GASGAS ECA 1 2023 has a starting price of 5308$. GASGAS ECA 3 2023 on the other hand is the most expensive at 6901$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Enduro e-bikes
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2023 and its price was 6901$. Comparing the average cost of an Enduro e-bike to this one, you will see that ECA 3 price is 44.22% higher.
ECA 3 components
Fork
This e-bike has the Fox Factory Float 38 fork installed. The fork’s travel is 170mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
As for the rear shock, this e-bike has the FOX Float X Factory model, with a travel of 160mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the ECA 3 e-bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. GASGAS ECA 3 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
GASGAS ECA 3 e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
The GASGAS model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
