Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Travel Front 170mm -
Travel Rear 160mm -
Fork DVO Onyx SC
-
Groupset X0 Eagle Transmission, SRAM -
Suspension Full -
Motor 250W 90Nm mid-drive -
Battery SRAM Eagle Powertrain, 630 Wh -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29", Carbon, Integrated battery, Boost, 160 mm
Suspension Fork
DVO Onyx D1CV OTT, Air, 170 mm, tapered
Rear Shock
DVO JadeX CV Coil, Coil, 205x65 mm
Drivetrain
Rear Derailleur
SRAM X0 Eagle Transmission, 12-S
Shift Levers
SRAM AXS Pod Ultimate Controller
Cassette
SRAM XS-1295, 10-52 T
Crank
SRAM XX Eagle Transmission
Chain
SRAM X0 Eagle Transmission Flattop
Chain Guide
Direct Mount
Pedals
GASGAS, aluminum
Wheels
Rims
Front: Rim: NEWMEN Evolution SL E.G. 30, Tubeless ready / Hub: 6-hole, 15x110 mm, thru axle, Rear: Rim: NEWMEN Evolution SL E.G. 35, Tubeless ready / Hub: 6-hole, 12x148 mm, thru axle
Tires
Maxxis Assegai, 63-622, 29x2.5,
Brakes
Brakes
Front: SRAM Code RSC, 4-piston, Hydraulic disc brake, Rear: SRAM Code RSC, 4-piston, Hydraulic disc brake
Cockpit
Stem
NEWMEN Evolution 318.40, Ahead
Handlebar
NEWMEN Advanced 318.25, 800 mm, Rise: 25 mm
Grips
GASGAS MTB, Lock-on grips
Headset
Acros AZX-579 ZS56/ZS56
Seat
Saddle
Selle Royal Terra Ridon X5
Seatpost
RockShox Reverb AXS
Motor & Battery
Motor
SRAM Eagle Powertrain Drive Unit, 250 W, 90 Nm
Battery
SRAM Eagle Powertrain, 630 Wh
Charger
SRAM Eagle Powertrain Charger, 4 A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.442 mm | 1.396 mm | 1.352 mm |
| Front Center | 798 mm | 826 mm | 858 mm |
| Rake | 41 mm | 38 mm | 38 mm |
| Trail | 137 mm | 140 mm | 140 mm |
| Stack | 649 mm | 663 mm | 676 mm |
| Reach | 450 mm | 475 mm | 500 mm |
| Top Tube Length | 588 mm | 613 mm | 638 mm |
| Seat Tube Angle | 76 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 440 mm | 470 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 115 mm | 130 mm | 145 mm |
| Chainstay Length | 461 mm | 465 mm | 469 mm |
| Wheelbase | 1257 mm | 1289 mm | 1325 mm |
| Bottom Bracket Drop | 31 mm | 31 mm | 31 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
ECC 6 completes the Gasgas E Ecc model. GASGAS launched 3 e-bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
The most economical model, the GASGAS ECC 4 2023 has a starting price of 7729$. GASGAS ECC 6 2023 on the other hand is the most expensive at 11041$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro e-bikes
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 11041$. In conclusion, this e-bike price is 130.74% more expensive than the price of the average Enduro e-bike.
Overview of components
Fork
The DVO Onyx SC is included from the factory. It has a travel distance of 170mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this e-bike has the DVO JadeX CV Coil model, with a travel of 160mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When it comes to wheels, the ECC 6 e-bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The ECC 6 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
GASGAS ECC 6 e-bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
GASGAS ECC 6 includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
