Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 140mm -
Fork RockShox Lyrik Select+
-
Groupset GX Eagle, SX Eagle -
Suspension Full -
Motor 250W 90Nm mid-drive -
Battery SRAM Eagle Powertrain, 630 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29/27.5", Carbon, Integrated battery, Boost, 140 mm
Suspension Fork
RockShox Lyrik Select+, DebonAir+, Air, 160 mm, tapered
Rear Shock
RockShox Deluxe Select+, Air, 205x60 mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-S
Shift Levers
SRAM SX Eagle, Single Click
Cassette
SRAM PG-1210, 11-50 T
Crank
SRAM XX Eagle Transmission
Chain
SRAM SX Eagle
Chain Guide
Direct Mount
Pedals
GASGAS, aluminum
Wheels
Rims
Front: Rim: Mach 1 TRUCKY 30, With eyelets, Tubeless ready / Hub: GASGAS DA210F, 6-hole, 15x110 mm, thru axle, Rear: Rim: Mach 1 TRUCKY 30, With eyelets, Tubeless ready / Hub: GASGAS DA210R, 6-hole, 12x148 mm, thru axle
Tires
Maxxis Assegai, 63-622, 29x2.5,
Brakes
Brakes
Front: SRAM DB8, 4-piston, Hydraulic disc brake, Rear: SRAM DB8, 4-piston, Hydraulic disc brake
Cockpit
Stem
GASGAS 35, 0 °, Ahead
Handlebar
GASGAS Riser 35 mm, 780 mm, Sweep: 9 °, Rise: 20 mm
Grips
GASGAS MTB, Lock-on grips
Headset
Acros AZX-579 ZS56/ZS56
Seat
Saddle
Selle San Marco GND
Seatpost
GASGAS Pro, 34.9 mm, Dropper post
Motor & Battery
Motor
SRAM Eagle Powertrain Drive Unit, 250 W, 90 Nm
Battery
SRAM Eagle Powertrain, 630 Wh
Charger
SRAM Eagle Powertrain Charger, 4 A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.492 mm | 1.4 mm | 1.356 mm |
| Bottom Bracket Height | 324 mm | 324 mm | 324 mm |
| Front Center | 788 mm | 819 mm | 851 mm |
| Rake | 36 mm | 44 mm | 45 mm |
| Trail | 130 mm | 121 mm | 120 mm |
| Stack | 664 mm | 658 mm | 671 mm |
| Reach | 445 mm | 470 mm | 495 mm |
| Top Tube Length | 588 mm | 613 mm | 638 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 440 mm | 470 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 120 mm | 135 mm | 150 mm |
| Chainstay Length | 442 mm | 445 mm | 450 mm |
| Wheelbase | 1228 mm | 1262 mm | 1299 mm |
| Bottom Bracket Drop | 31 mm | 31 mm | 31 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
MXC 4 belongs to the Gasgas E Mxc model. GASGAS released 3 e-bikes variations of this model so far. Take a sneak peek at all Gasgas E Mxc e-bikes models from 2023, by clicking here.
Model range prices
GASGAS MXC 4 2023 is the most affordable e-bike of this model and has a price of 7729$. On the other hand, GASGAS MXC 6 2023, is the most expensive and costs 11041$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail e-bikes
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
When GASGAS released this model in 2023, its price was 7729$. Doing a quick comparison, we notice that MXC 4 price is 129.69% higher than the average cost of a Trail e-bike.
MXC 4 components
Fork
The fork installed on this bike is the RockShox Lyrik Select+ model. The travel on this model is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The MXC 4 has a rear shock with a travel of 140mm. The model RockShox Deluxe Select+ is the one installed in this e-bike. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When it comes to wheels, the MXC 4 e-bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
GASGAS MXC 4 comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
